Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Groupset microSHIFT Advent -
Suspension Rigid -
Drivetrain 1 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 triple butted aluminium, QR, rack / fender mounts, 68 mm BSA shell
Suspension Fork
6061 aluminium, QR dropouts, with fender / rack / triple cage mounts, internal light cable routing
Drivetrain
Rear Derailleur
MICROSHIFT RD-M6195M, clutch
Front Derailleur
-
Shift Levers
MICROSHIFT ADVENT SB-M090 dual control lever 1 x 9
Cassette
MICROSHIFT CS-H093 9-speed, 11 - 46 T
Crank
BOMBTRACK AF19 aluminium crank, square taper
Bottom Bracket
BSA sealed BB, 119 mm, square taper
Chain
KMC X9 chain, 1/2'' x 11/128'', 114L
Pedals
WELLGO B109N flat pedal
Wheels
Front Hub
BOMBTRACK ARC sealed hub, 6-bolt disc, hex key skewer
Rear Hub
BOMBTRACK ARC sealed hub, 11-speed, 6-bolt disc, hex key skewer
Rims
WTB ST i21 double wall, TCS 2.0, 32h
Tires
KENDA KWICK SEVEN.5 650B x 45C
Brakes
Brakes
TEKTRO MIRA post mount mechanic disc brakes with 160 mm rotors
Cockpit
Stem
BOMBTRACK ROAM forged aluminium stem, -7°
Handlebar
BOMBTRACK CX-10 drop bar, 31.8 mm, 10° flare
Grips
BOMBTRACK COMMAND bar tape
Headset
NECO H282 sealed external aheadset, 1.1/8''
Seat
Saddle
BOMBTRACK FUZZ
Seatpost
BOMBTRACK BEECH aluminium seatpost, 27.2 mm x 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 7.533 mm | 7.773 mm | 8.093 mm |
| Front Center | 595 mm | 619 mm | 645 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 74 mm | 74 mm | 74 mm |
| Stack | 570 mm | 588 mm | 612 mm |
| Top Tube Length | 545 mm | 568 mm | 593 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 520 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 130 mm | 150 mm | 175 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1030 mm | 1054 mm | 1080 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 771 mm | 795 mm | 821 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
MUNROE SG is part of the Bombtrack Munroe model. Bombtrack released 8 bikes variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid bikes average price
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
MUNROE SG components
Fork material
The fork is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
The MUNROE SG 2022 bike is equipped with aluminum wheels when leaving the factory. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The MUNROE SG has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
