Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 700c -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 crmo front triangle, crmo dropouts with fender mounts, 68 mm BSA shell
Suspension Fork
full 4130 crmo fork, 1" steerer, with rack and fender mounts
Drivetrain
Rear Derailleur
-
Front Derailleur
-
Shift Levers
-
Cassette
16T freewheel, 1/2" x 3/32"
Crank
BOMBTRACK AF22 alloy crank, square taper, BOMBTRACK BIRO alloy, 44T
Bottom Bracket
BSA sealed BB, 113.5 mm, square taper
Chain
KMC 510HX chain, 1/2" x 1/8", 98L
Pedals
BOMBTRACK STROLL alloy pedal
Wheels
Front Hub
Front: BOMBTRACK DROME sealed front hub, 9mm female bolt axle, Rear: BOMBTRACK DROME sealed freewheel hub, 10 mm female bolt axle
Rear Hub
Front: BOMBTRACK DROME sealed front hub, 9mm female bolt axle, Rear: BOMBTRACK DROME sealed freewheel hub, 10 mm female bolt axle
Rims
Front: BOMBTRACK DRX double wall, i16, 28h, Rear: BOMBTRACK DRX double wall, i16, 28h
Tires
Front: KENDA KWICK ROLLER tire, 700C x 28C, Rear: KENDA KWICK ROLLER tire, 700C x 28C
Brakes
Brakes
TEKTRO R359 alloy caliper brakes
Cockpit
Stem
BOMBTRACK JAUNT forged alloy quill stem, -17°
Handlebar
BOMBTRACK HORIZON flat bar, 560 mm, 25.4 mm, 8° backsweep
Grips
BOMBTRACK SPACE 130 mm grip with leather bar tape
Headset
FSA DURON X sealed external headset, 1" threaded
Seat
Saddle
BOMBTRACK Team saddle
Seatpost
BOMBTRACK MYRTLE alloy seatpost, 27.2 mm x 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.43 mm | 1.46 mm | 1.49 mm |
| Front Center | 596 mm | 602 mm | 617 mm | 631 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 73 mm | 64 mm | 60 mm | 58 mm |
| Stack | 502 mm | 532 mm | 559 mm | 588 mm |
| Reach | 363 mm | 372 mm | 383 mm | 394 mm |
| Top Tube Length | 519 mm | 537 mm | 557 mm | 576 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 510 mm | 540 mm | 570 mm | 600 mm |
| Head Tube Angle | 69.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 101 mm | 126 mm | 153 mm | 181 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 994 mm | 1000 mm | 1015 mm | 1030 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 748 mm | 778 mm | 806 mm | 835 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Oxbridge is part of the Bombtrack Oxbridge model. There are 8 bikes that carry this model name. Check out the entire range from 2020 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
General Urban bikes average price
If you want an acceptable General Urban bike you should know that the average price is 499$. However, this doesn’t mean that if you spend less money on a General Urban bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
General Urban bikes average weight
General Urban bikes have an average weight of 13.11 kg (28.9 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Oxbridge weighs 10.4 kg (22.93 lbs) and is much lighter than the average. In short, the average General Urban bike weight is 26.06% higher than this one.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
As for the wheels, Bombtrack Oxbridge 2020, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
