Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Groupset Apex -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 double butted aluminium, TA, rack / fender mounts, 86.5 mm BB T47 shell
Suspension Fork
Full carbon, TA, 1.1/2'' - 1.1/8'', fender mounts
Drivetrain
Rear Derailleur
SRAM APEX 1, clutch, long cage
Front Derailleur
-
Shift Levers
SRAM APEX 1 double tap 1 x 11
Cassette
SRAM PG-1130 11-speed, 11 - 42 T
Crank
BOMBTRACK LYER forged aluminium crank, direct mount interface, (SRAM compatible),30 mm spindle
Bottom Bracket
BOMBTRACK T47 internal sealed BB for 30 mm spindle
Chain
KMC X11 chain, 1/2'' x 11/128'', 114L
Pedals
-
Wheels
Front Hub
BOMBTRACK ARC sealed hub, 6-bolt disc
Rear Hub
BOMBTRACK ARC sealed hub, 11-speed, 6-bolt disc
Rims
WTB ST i19 double wall, TCS 2.0, 32h
Tires
Front: XS - S VEE TIRE XCX 120 TPI TLR 32-584 /, M - XL CHALLENGE GRIFO TLR 33-622, tubeless ready, Rear: XS - S VEE TIRE XCX 120 TPI TLR 32-584 /, M - XL CHALLENGE GRIFO TLR 33-622, tubeless ready
Brakes
Brakes
SRAM APEX flat mount hydraulic disc brakes with 140 mm rotors
Cockpit
Stem
BOMBTRACK ROAM forged aluminium stem, -7°
Handlebar
BOMBTRACK CX-10 drop bar, 31.8 mm, 10° flare
Grips
BOMBTRACK COMMAND bar tape
Headset
Sealed integrated aheadset, 1.1/2'' - 1.1/8''
Seat
Saddle
BOMBTRACK DART saddle
Seatpost
BOMBTRACK BEECH 27.2 mm x 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.46 mm | 1.49 mm | 1.51 mm | 1.51 mm |
| Front Center | 563 mm | 575 mm | 598 mm | 611 mm | 627 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 67 mm | 64 mm | 70 mm | 66 mm | 66 mm |
| Stack | 506 mm | 522 mm | 555 mm | 579 mm | 595 mm |
| Reach | 347 mm | 358 mm | 372 mm | 383 mm | 394 mm |
| Top Tube Length | 499 mm | 515 mm | 544 mm | 562 mm | 578 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 490 mm | 530 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 115 mm | 139 mm | 162 mm | 179 mm |
| Chainstay Length | 402 mm | 402 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 959 mm | 971 mm | 1006 mm | 1020 mm | 1036 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 726 mm | 749 mm | 791 mm | 817 mm | 840 mm |
| Wheels | 650 | 650 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
TENSION 1 completes the Bombtrack Tension model. There are 16 bikes that carry this model name. Take a sneak peek at all Bombtrack Tension bikes models from 2023, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Cyclocross bikes
If you want to purchase a solid Cyclocross bike, it is important to know that the average cost is 2012$. However, even if your budget is less than the average, you might still be able to get a top-quality Cyclocross bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Cyclocross bikes
Cyclocross bikes have an average weight of 8.79 kg (19.38 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
a bit heavier than average, TENSION 1 has a weight of 9.4 kg (20.72 lbs). In other words, this model is 6.94% heavier than the average Cyclocross bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
As for the wheels, Bombtrack TENSION 1 2023, has a aluminum model. After 700c wheels, 650b is the second most popular choice for road bikes. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The TENSION 1 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
