Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Groupset Rival -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 double butted aluminium, TA, rack / fender mounts, 86.5 mm BB T47 shell
Suspension Fork
full carbon, TA, 1.1/2'' - 1.1/8'', fender mounts
Drivetrain
Rear Derailleur
SRAM RIVAL 1, clutch, long cage
Front Derailleur
-
Shift Levers
SRAM RIVAL 1 double tap 1 x 11
Cassette
SRAM PG-1130 11-speed, 11 - 36 T
Crank
BOMBTRACK LYER forged aluminium crank, direct mount interface, (SRAM compatible),30 mm spindle
Bottom Bracket
BOMBTRACK T47 internal sealed BB for 30 mm spindle
Chain
KMC X11 EPT Anti Rust chain, 1/2'' x 11/128'', 114L
Pedals
-
Wheels
Front Hub
HUNT 4 SEASON V2 sealed hub, 6-bolt disc
Rear Hub
HUNT 4 SEASON V2 sealed hub, 11-speed, 6-bolt disc
Rims
HUNT 4 SEASON double wall asymmetric rim, TLC, i19, 24h
Tires
Front: XS - S VEE TIRE XCX 120 TPI TLR 32-584 /, M - XL CHALLENGE GRIFO TLR 33-622, tubeless ready, Rear: XS - S VEE TIRE XCX 120 TPI TLR 32-584 /, M - XL CHALLENGE GRIFO TLR 33-622, tubeless ready
Brakes
Brakes
SRAM RIVAL flat mount hydraulic disc brakes with 140 mm rotors
Cockpit
Stem
RITCHEY COMP 4-AXIS 44 aluminium stem, -6°
Handlebar
RITCHEY ROAD COMP STREEM III drop bar, 31.8 mm, 5° backsweep
Grips
BOMBTRACK COMMAND bar tape
Headset
Sealed integrated aheadset, 1.1/2'' - 1.1/8''
Seat
Saddle
BOMBTRACK DART saddle
Seatpost
RITCHEY COMP 2-BOLT aluminium seatpost 27.2 mm x 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.46 mm | 1.49 mm | 1.51 mm | 1.51 mm |
| Front Center | 563 mm | 575 mm | 598 mm | 611 mm | 627 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 67 mm | 64 mm | 70 mm | 66 mm | 66 mm |
| Stack | 506 mm | 522 mm | 555 mm | 579 mm | 595 mm |
| Reach | 347 mm | 358 mm | 372 mm | 383 mm | 394 mm |
| Top Tube Length | 499 mm | 515 mm | 544 mm | 562 mm | 578 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 490 mm | 530 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 115 mm | 139 mm | 162 mm | 179 mm |
| Chainstay Length | 402 mm | 402 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 959 mm | 971 mm | 1006 mm | 1020 mm | 1036 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 726 mm | 749 mm | 791 mm | 817 mm | 840 mm |
| Wheels | 650 | 650 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
TENSION 2 is part of the Bombtrack Tension model. Bombtrack launched 16 bikes of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Cyclocross bikes
According to our math, the average price for a trustworthy Cyclocross bike is 2012$. However, even if your budget is less than the average, you might still be able to get a top-quality Cyclocross bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Cyclocross bikes average weight
The average weight for Cyclocross bikes is 8.79 kg (19.38 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
slightly heavier than average, TENSION 2 has a weight of 8.9 kg (19.62 lbs). In conclusion, the average Cyclocross bike weighs 1.25% less than TENSION 2.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When leaving the production line, the TENSION 2 model has aluminum wheels. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
When you want to stop the bike in time, the brakes are vital. The TENSION 2 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Bombtrack TENSION 2 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
