Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Suspension Rigid -
Drivetrain Belt Drive -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Breezer D'Fusion hydroformed aluminum, integrated head tube, dual water bottle mounts, Breezer Eccentric bottom bracket
Suspension Fork
Breezer aluminum, chromoly steerer, Low-Rider rack mounts
Drivetrain
Shift Levers
Nuvinci N360 Twist Shifter, ∞ - Speed
Cassette
Gates CDX CenterTrack Pulley
Crank
Breezer Forged Aluminum, Gates CDX CenterTrack Pulley
Bottom Bracket
VP-BC73C Cartridge Style
Chain
Gates CDX CenterTrack Carbon Drive Belt
Pedals
VP, Polished Aluminum Body, CrMo axle
Wheels
Rims
Shimano DH-3D30 QR Dynamo Front/Nuvinci N360 Continuously Variable Planetary Rear, 32H 6-Bolt Hubs, Alex TD25 Rims
Tires
Schwalbe Marathon, 700Cx35, Green Guard
Brakes
Brakes
Tektro Auriga SUB Hydraulic Disc Brake, 160mm Front, 160mm Rear
Brake Levers
Tektro Auriga SUB Hydraulic Disc Brake
Cockpit
Stem
Breezer Aluminum, 25.4, 7° FlipFlop, Ahead Style
Handlebar
Breezer Aluminum, 25.4, 26mm rise, 590mm wide, 33° sweep
Headset
Oval 1 1/8", Fully Integrated, Full-Cartridge Angular Contact Bearings
Seat
Saddle
Breezer Performance Saddle
Seatpost
Breezer Aluminum, 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 626.2 mm | 636.9 mm | 647.5 mm | 668.2 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 585 mm | 595 mm | 605 mm | 625 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 520 mm | 560 mm | 600 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 140 mm | 155 mm | 170 mm | 190 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1069 mm | 1080 mm | 1090 mm | 1111 mm |
| Standover Height | 775 mm | 792 mm | 825 mm | 851 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Beltway ∞ is a Breezer Beltway model. 37 bikes variations carry this model name so far. You can easily view all of the Breezer Beltway bikes models from 2012, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Commuter bikes
Our math shows that the average cost of a dependable Commuter bike is 762$. However, even though the average price of a Commuter bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
When leaving the production line, the Beltway ∞ model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Breezer Beltway ∞ has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
