Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NCX
-
Groupset XT, Alivio -
Suspension Hardtail -
Motor 250W mid-drive -
Battery TranzX Lithium-Polymer 36V 10Ah Battery (100km Range)* -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Breezer D'Fusion Hydroformed Aluminum, Integrated Head Tube, Dual Water Bottle Mounts
Suspension Fork
Suntour NCX-D LO Lite, Hydraulic Speed-Loc, Disc-Only, 63mm Travel
Drivetrain
Rear Derailleur
Shimano Deore XT Trekking 9-Speed, SGS
Front Derailleur
Shimano Alivio Trekking 9-Speed, 34.9mm
Shift Levers
Shimano Alivio 27-Speed
Cassette
Shimano HG 9-Speed, 11-32T
Crank
Shimano M431 Trekking 9-Speed, w/ Chainguard, 48-36-26T
Bottom Bracket
TranzX Cartridge-Style, Torque Sensor Unit
Chain
KMC Z 9-Speed
Pedals
VP, Polished Aluminum Body, Chromoly Axle
Wheels
Rims
Shimano 3D30 3W Dynamo Disc QR Front/TranzX PST M08 36V 250W Disc Rear, 36H Hubs, Vera DPD23 Disc Rims
Tires
Schwalbe Energizer, w/ KevlarGuard, 40-622
Brakes
Brakes
Tektro Auriga SUB Trekking Hydraulic Disc Brake, 160mm Front, 160mm Rear
Brake Levers
Tektro Auriga SUB Trekking Hydraulic Disc Brake, 4-Finger Lever
Cockpit
Stem
Breezer Forged 6061 Aluminum, 25.4, Adjustable 0~60°, Ahead-Style
Handlebar
Breezer Ergo 6061 Aluminum, 25.4, 630mm Wide, 30mm Rise, 9° Sweep
Headset
FSA 1 1/8", Fully Integrated, 36° ACB-Sealed, 15mm Aluminum Top Cover
Seat
Saddle
Breezer Comfort Saddle
Seatpost
Breezer Aluminum, 27.2mm
Motor & Battery
Motor
TranzX PST M19 36V 250W Rear Motor
Battery
TranzX Lithium-Polymer 36V 10Ah Battery (100km Range)*
Remote
TranzX LCD DP10, Remote w/ Auto Sensor
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm | 286 mm |
| Front Center | 625 mm | 635.9 mm | 646.4 mm | 667.1 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm |
| Top Tube Length | 585 mm | 595 mm | 605 mm | 625 mm |
| Seat Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 480 mm | 520 mm | 560 mm | 600 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 120 mm | 140 mm | 155 mm | 170 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1068 mm | 1078 mm | 1089 mm | 1110 mm |
| Standover Height | 790 mm | 816 mm | 840 mm | 866 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
e-Liberty completes the Breezer E E Liberty model. Breezer released 6 e-bikes variations of this model so far. You can easily view all of the Breezer E E Liberty e-bikes models from 2013, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Hybrid e-bikes
Our math shows that the average cost of a dependable Hybrid e-bike is 2480$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
The e-Liberty comes factory-installed with the SunTour NCX fork. This has a travel range of 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
As for the wheels, Breezer e-Liberty 2013, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The e-Liberty has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Breezer e-Liberty e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
