Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset XT, Alivio -
Suspension Hardtail -
Motor Bosch 250W mid-drive -
Battery Bosch Active Line PowerPack 400, Lithium-Ion, 36V, 11Ah, 400Wh -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hydroformed Aluminum, Integrated Head Tube, Bosch Interface
Suspension Fork
Suntour NEX MLO, MC-Lockout, Disc-Only, 63mm Travel
Drivetrain
Rear Derailleur
Shimano Deore XT Trekking 9-Speed, SGS
Shift Levers
Shimano Alivio 9-Speed
Cassette
Shimano HG 9-Speed, 11-34T
Crank
Miranda Alfa Isis, w/ Chainguard
Bottom Bracket
Bosch Drive Unit
Chain
Shimano HG 9-Speed
Pedals
VP, Polished Aluminum Body, Chromoly Axle
Wheels
Rims
Shimano 3D35 3W Dynamo CenterLock Disc QR Front/Shimano RM66 CenterLock Disc QR Rear, 32H Hubs, Mach 1 Aluminum Disc-Only Rims
Tires
Continental Contact 2 Reflex, 42-622
Brakes
Brakes
Shimano M395 Hydraulic Disc Brake, 160mm Front, 160mm Rear
Brake Levers
Shimano M395 Hydraulic Disc Brake
Cockpit
Stem
Breezer Forged 6061 Aluminum, 25.4, Adjustable 0~60°, Ahead-Style
Handlebar
Breezer City 6061 Aluminum, 25.4
Headset
1 1/8", Zero Stack, Sealed
Seat
Saddle
Selle Bassano Volare He
Seatpost
Breezer Suspension Aluminum, 40mm Travel, 27.2mm
Motor & Battery
Motor
Bosch Active Line Drive Unit, 250 watts, 25 km/h
Battery
Bosch Active Line PowerPack 400, Lithium-Ion, 36V, 11Ah, 400Wh
Remote
Bosch Active line Intuvia Computer Control Center
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Front Center | 655 mm | 670 mm | 685 mm |
| Rake | 44.5 mm | 44.5 mm | 44.5 mm |
| Top Tube Length | 599 mm | 614 mm | 629 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 185 mm | 195 mm | 195 mm |
| Chainstay Length | 484 mm | 484 mm | 484 mm |
| Wheelbase | 1132 mm | 1148 mm | 1162 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 480 mm | 476 mm | 464 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
E-Liberty – LS is a Breezer E E Liberty model. Breezer launched 6 e-bikes of this model so far. Check out the entire range from 2014 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Hybrid e-bikes
If you want to purchase a solid Hybrid e-bike, it is important to know that the average cost is 2480$. However, you could also get a good Hybrid e-bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
E-Liberty – LS components
Fork
The fork installed on this bike is the SunTour NEX model. The travel on this model is 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on E-Liberty – LS are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The E-Liberty – LS has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
E-Liberty – LS comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
