Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NCX
-
Groupset Nexus, Shimano -
Suspension Hardtail -
Motor Shimano mid-drive -
Battery Shimano STePS -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hydroformed Aluminum, Integrated Head Tube, Shimano STePS Interface
Suspension Fork
Suntour NCX, Lockout, 63mm Travel
Drivetrain
Shift Levers
Shimano Nexus 8 Revo-Shift, 8-Speed
Cassette
Shimano, 20T
Crank
Shimano STePS 38 T
Bottom Bracket
Shimano STePS
Chain
KMC Z-610
Pedals
VP, Polished Aluminum Body, Chromoly Axle
Wheels
Rims
Shimano HB-RM66 CenterLock Disc QR Front, Shimano Nexus 8 Rear, 36H Centerlock Hubs, Mach 1 Aluminum Disc-Only Rims
Tires
Continental Town Ride Reflex 42-622, Puncture Protection
Brakes
Brakes
Shimano BL-T 445 Hydraulic Disc Brake, 160mm Front, 160mm Rear
Brake Levers
Shimano BL-T 445 Hydraulic Disc Brake, 4-Finger Lever
Cockpit
Stem
Breezer Forged 6061 Aluminum, 25.4, Adjustable 0~60°, Ahead-Style / Speedlifter Twist
Handlebar
Breezer Ergo Lite 6061 Aluminum, 25.4, 590mm Wide, 26mm Rise, 33° Sweep
Headset
1 1/8", Zero Stack, Sealed + SPEEDLIFTER TWIST (Stem adjustable adapter)
Seat
Saddle
Selle Royal Freeway DRC, Look In Design
Seatpost
Breezer Suspension Aluminum, 40mm Travel, 27.2mm
Motor & Battery
Motor
Shimano STePS
Battery
Shimano STePS
Remote
Shimano STePS
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm | 283 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 582 mm | 582 mm | 592 mm | 607 mm |
| Seat Tube Angle | 74 ° | 73 ° | 71 ° | 71 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 140 mm | 140 mm | 155 mm | 170 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1094 mm | 1091 mm | 1088 mm | 1106 mm |
| Standover Height | 369 mm | 369 mm | 382 mm | 387 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
Greenway IG + LS belongs to the Breezer E Greenway model. There are 23 e-bikes that carry this model name. Take a sneak peek at all Breezer E Greenway e-bikes models from 2016, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Commuter e-bikes
If you want an acceptable Commuter e-bike you should know that the average price is 2569$. However, even though the average price of a Commuter e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The fork installed on this bike is the SunTour NCX model. The travel on this model is 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
As for the wheels, Breezer Greenway IG + LS 2016, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Greenway IG + LS comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Breezer Greenway IG + LS e-bike has 4 sizes, in the range of 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, it won’t be difficult to find the right one for you.
