Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Ultegra, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
158cm - 167cm
SM
165cm - 173cm
MD
169cm - 180cm
LG
177cm - 186cm
XL
183cm - 191cm
XXL
186cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Breezer D'Fusion fully-butted chromoly steel, tapered head tube, BB92, 142X12 through-axle dropouts
Suspension Fork
Carbon disc, tapered carbon steerer, 12mm through-axle
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano STR-685, STI Hydraulic Disc
Cassette
Shimano Ultegra, 11-28
Crank
Praxis Zyante, Hollow-forged w/30mm Spindle, 50/34T
Bottom Bracket
Praxis BB86
Chain
KMC X11
Pedals
na
Wheels
Rims
WTB Frequency Team Disc, TCS Tubeless Compatible, Formula sealed-bearing 12mm through-axle hubs, 28H
Tires
WTB Exposure TCS, 30c, Tubeless Compatible
Brakes
Brakes
Shimano BR-785, hydraulic disc, Ice-Tech resin pads w/ fins, 160mm / 140mm
Brake Levers
Shimano
Cockpit
Stem
Oval Concepts 777SL, 3D-forged & internally machined stem body, +/-7°
Handlebar
Oval Concepts 725, 7050 alloy, 31.8mm clamp, 125mm drop, 25° flare, 4° sweep
Headset
FSA 1 1/8"-1.5", Fully Integrated, 36° ACB-Sealed, 6.5mm Aluminum Top Cover
Seat
Saddle
WTB Volt Race 142x265, CroMo Rail
Seatpost
Oval Concepts 850, carbon, 27.2mm diameter
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.46 mm | 1.47 mm | 1.52 mm | 1.56 mm | 1.62 mm |
| Bottom Bracket Height | 271 mm | 271 mm | 274 mm | 274 mm | 277 mm | 277 mm |
| Front Center | 583 mm | 594 mm | 603 mm | 609 mm | 621 mm | 626 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 69 mm | 66 mm | 59 mm | 63 mm | 63 mm | 60 mm |
| Stack | 536.02 mm | 552.05 mm | 565.13 mm | 588.91 mm | 609.68 mm | 635.47 mm |
| Reach | 368.6 mm | 378.73 mm | 383.49 mm | 386.32 mm | 390.35 mm | 393.29 mm |
| Seat Tube Angle | 75 ° | 74 ° | 72 ° | 73 ° | 72 ° | 72 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm | 600 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72.5 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm | 155 mm | 180 mm | 205 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 995 mm | 1006 mm | 1016 mm | 1022 mm | 1035 mm | 1040 mm |
| Bottom Bracket Drop | 78 mm | 78 mm | 75 mm | 75 mm | 72 mm | 72 mm |
| Standover Height | 705 mm | 728 mm | 753 mm | 780 mm | 808 mm | 835 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 165 cm | 169 cm | 177 cm | 183 cm | 186 cm |
| Rider Max Height | 167 cm | 173 cm | 180 cm | 186 cm | 191 cm | 194 cm |
Model Overview
Inversion Team belongs to the Breezer Inversion model. Breezer launched 13 bikes of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Gravel bikes average weight
If we make a quick analysis of the average weight of a Gravel bike, we get 8.13 kg (17.92 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
considerably heavier than average, Inversion Team has a weight of 9.13 kg (20.13 lbs). In short, the average Gravel bike weight is 12.3% lower than this one.
Overview of components
Fork material
Inversion Team has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the Inversion Team bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Inversion Team has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This bike is available in 6 sizes. They vary from 158 cm – 194 cm (5.18 ft – 6.36 ft). In conclusion, you won’t have a problem finding one that suits you.
