Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NCX
-
Groupset Deore, Acera -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Breezer D'Fusion Hydroformed Aluminum, Integrated Head Tube, Single Water Bottle Mount
Suspension Fork
Suntour NCX-D MLO, MC-Lockout, Disc-Only, 63mm Travel
Drivetrain
Rear Derailleur
Shimano Deore Trekking 9-Speed, SGS
Front Derailleur
Shimano Acera Trekking 9-Speed, 34.9mm
Shift Levers
Shimano Alivio 27-Speed
Cassette
Shimano HG 9-Speed, 11-32T
Crank
Shimano M431 Trekking 9-Speed, w/ Chainguard, 48-36-26T
Bottom Bracket
Shimano ES25, Octalink, Hollow-Type
Chain
KMC Z 9-Speed
Pedals
VP, Chromoly Axle
Wheels
Rims
Shimano 3D30 3W Dynamo Disc QR Front/Shimano M475 Disc QR Rear, 36H Hubs, Rigida Taurus 19 Disc-Only Rims
Tires
Continental TownRIDE Reflex, 42-622
Brakes
Brakes
Tektro Draco 2 Hydraulic Disc Brake, 160mm Front, 160mm Rear
Brake Levers
Tektro Draco 2 Hydraulic Disc Brake, 3-Finger Lever
Cockpit
Stem
Breezer Forged 6061 Aluminum, 25.4, Adjustable 0~60°, Ahead-Style
Handlebar
Breezer Ergo-L 6061 Aluminum, 25.4, 610mm Wide, 30mm Rise, 15° Sweep
Headset
FSA 1 1/8", Fully Integrated, 36° ACB-Sealed, 15mm Aluminum Top Cover
Seat
Saddle
Selle Royal Premium Nuvola
Seatpost
Breezer Aluminum, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm | 286 mm |
| Front Center | 614.3 mm | 621.8 mm | 616.1 mm | 626.8 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm |
| Top Tube Length | 570 mm | 575 mm | 580 mm | 590 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 400 mm | 460 mm | 500 mm | 540 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 105 mm | 120 mm | 140 mm | 155 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1052 mm | 1059 mm | 1054 mm | 1064 mm |
| Standover Height | 696 mm | 720 mm | 737 mm | 753 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Liberty 3 ST belongs to the Breezer Liberty model. 141 bikes variations carry this model name so far. You can easily view all of the Breezer Liberty bikes models from 2013, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Hybrid bikes
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Liberty 3 ST components
Fork
This bike has the SunTour NCX fork installed. The fork’s travel is 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Breezer Liberty 3 ST 2013, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Liberty 3 ST comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, it won’t be difficult to find the right one for you.
