Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Altus, Shimano -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Coaster
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Breezer D'Fusion Hydroformed Aluminum, Integrated Head Tube, Dual Water Bottle Mounts
Suspension Fork
Suntour NEX, 63mm Travel
Drivetrain
Rear Derailleur
Shimano Altus Trekking 8-Speed, SGS
Front Derailleur
Shimano Altus Trekking 8-Speed, 34.9mm
Shift Levers
Shimano EF51 24-Speed
Cassette
Shimano HG 8-Speed, 11-32T
Crank
Shimano M131 Trekking 8-Speed, w/ Chainguard, 48-38-28T
Bottom Bracket
FSA 7420 Cartridge-Style
Chain
KMC 8-Speed
Pedals
VP, Chromoly Axle
Wheels
Rims
Shimano 3N31 3W Dynamo Front/Shimano RM30 QR Rear, 36H Hubs, Vera DPM18 GSW Rims
Tires
Continental TownRIDE Reflex, 42-622
Brakes
Brakes
Forged Aluminum V-Brake, Stainless Hardware / Coaster Brake
Brake Levers
Shimano EZ-Fire, 4-Finger Lever
Cockpit
Stem
Breezer Forged 6061 Aluminum, 25.4, Adjustable 0~60°, Ahead-Style
Handlebar
Breezer Ergo 6061 Aluminum, 25.4, 630mm Wide, 30mm Rise, 9° Sweep
Headset
FSA 1 1/8", Fully Integrated, 36° ACB-Sealed, 15mm Aluminum Top Cover
Seat
Saddle
Selle Royal Rio
Seatpost
Breezer Aluminum, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm | 286 mm |
| Front Center | 625 mm | 635.9 mm | 646.4 mm | 667.1 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm |
| Top Tube Length | 585 mm | 595 mm | 605 mm | 625 mm |
| Seat Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 480 mm | 520 mm | 560 mm | 600 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 120 mm | 140 mm | 155 mm | 170 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1058 mm | 1069 mm | 1079 mm | 1100 mm |
| Standover Height | 790 mm | 816 mm | 840 mm | 866 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Liberty 5 is a Breezer Liberty model. 141 bikes variations carry this model name so far. Take a sneak peek at all Breezer Liberty bikes models from 2015, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Hybrid bikes average price
If you want to purchase a solid Hybrid bike, it is important to know that the average cost is 562$. However, even though the average price of a Hybrid bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork
Breezer Liberty 5 2015 bike is equipped with the SunTour NEX fork, and has 63mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When it comes to wheels, the Liberty 5 bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Coaster brakes. These brakes are pretty efficient, and they’re not so pricey. However, they have flaws, especially if the chain falls off.
Sizes
Liberty 5 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
