Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Deore, Altus -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Breezer D'Fusion Hydroformed Aluminum, Integrated Head Tube, Single Water Bottle Mount
Suspension Fork
Breezer Aluminum, Low-Rider Rack Mounts
Drivetrain
Rear Derailleur
Shimano Deore Trekking 9-Speed, SGS
Front Derailleur
Shimano Altus, 9-speed, 34.9mm
Shift Levers
Shimano Altus, 27-speed
Cassette
Shimano HG 9-Speed, 11-32T
Crank
Shimano M391 Trekking 9-Speed, w/ Chainguard, 48-36-26T
Bottom Bracket
FSA 7420 Cartridge-Style
Chain
KMC 9-Speed
Pedals
VP, Chromoly Axle
Wheels
Rims
Shimano 3N31 3W Dynamo QR Front/Shimano RM70 QR Rear, 32H Hubs, Vera DPM18 GSW Rims
Tires
Continental TownRIDE Reflex, 42-622
Brakes
Brakes
Shimano M422 V Brakes
Brake Levers
Shimano Alivio V-Brake Levers
Cockpit
Stem
Breezer 3D-Forged 6061 Aluminum, 31.8, 12°/78°
Handlebar
Breezer Ergo Lite 6061 Aluminum, 31.8, 610mm Wide, 15mm Rise, 15° Sweep
Headset
FSA 1 1/8", Fully Integrated, 36° ACB-Sealed, 15mm Aluminum Top Cover
Seat
Saddle
Selle Royal Premium Ariel
Seatpost
Breezer Aluminum, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Bottom Bracket Height | 270 mm | 270 mm | 275 mm | 275 mm | 275 mm |
| Front Center | 619.5 mm | 630.6 mm | 620.2 mm | 631.2 mm | 642.3 mm |
| Rake | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 555 mm | 570 mm | 580 mm | 590 mm | 600 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm | 560 mm |
| Head Tube Angle | 70 ° | 70 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 120 mm | 140 mm | 155 mm | 170 mm | 185 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1058 mm | 1069 mm | 1060 mm | 1071 mm | 1082 mm |
| Standover Height | 659 mm | 677 mm | 700 | 717 mm | 728 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Liberty Lite 3 – ST is a Breezer Liberty model. 141 bikes variations carry this model name so far. Take a sneak peek at all Breezer Liberty bikes models from 2015, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Hybrid bikes
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Liberty Lite 3 – ST components
Fork material
Liberty Lite 3 – ST has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The Liberty Lite 3 – ST 2015 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Liberty Lite 3 – ST comes with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
