Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Breezer D'Fusion Hydroformed Custom-Butted Aluminum, Integrated Head Tube
Suspension Fork
Rock Shox XC 28 TK Mg 29, Aluminum Steerer, 100mm Travel
Rear Shock
-
Drivetrain
Rear Derailleur
Shimano Deore XT 10-Speed, SGS, Shadow Design
Front Derailleur
Shimano Deore 10-Speed, 34.9mm
Shift Levers
Shimano Deore 30-Speed
Cassette
Shimano HG-62 10-Speed, 11-36T
Crank
Shimano M612 10-Speed, 40-30-22T
Bottom Bracket
Shimano Exterior Bearing System
Chain
KMC X10
Pedals
Wellgo Aluminum, Chromoly Axle
Wheels
Rims
Shimano M435 32H CenterLock Hubs, WTB SX19 29" Rims
Tires
WTB Bronson 29x2.2" Comp
Brakes
Brakes
Shimano M445 Hydraulic Disc Brake, 180mm Front, 160mm Rear
Brake Levers
Shimano M445 Hydraulic Disc Brake
Cockpit
Stem
Oval Concepts 313, 3D-Forged 6061 Aluminum, 31.8, 7°/83°
Handlebar
Oval Concepts 250, 6061 Aluminum, 31.8, 710mm Wide, +/- 5mm Rise, 9° Sweep
Headset
FSA IS-3 1 1/8", Fully Integrated, 36° ACB-Sealed, 9mm Aluminum Top Cover
Seat
Saddle
WTB Volt, Satin Steel Rail
Seatpost
Oval Concepts 300, 3D-Forged 6061 Aluminum, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 305 mm | 305 mm |
| Front Center | 612.7 mm | 628.5 mm | 643.5 mm | 653.4 mm | 668.4 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 572 mm | 587 mm | 602 mm | 612 mm | 627 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 380 mm | 430 mm | 470 mm | 500 mm | 530 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1048 mm | 1064 mm | 1079 mm | 1089 mm | 1104 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 763 mm | 783 mm | 807 mm | 826 mm | 845 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Storm Expert 29 completes the Breezer Storm model. 45 bikes variations carry this model name so far. You can get a glimpse at all models from 2014, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Crosscountry bikes
If we make a quick analysis of the average weight of a Crosscountry bike, we get 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
considerably heavier than average, Storm Expert 29 has a weight of 13.9 kg (30.64 lbs). In short, the average Crosscountry bike weight is 12.1% lower than this one.
Overview of components
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
When it comes to wheels, the Storm Expert 29 bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
