Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox Recon Silver RL
-
Groupset SLX, Deore -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Breezer D'Fusion Hydroformed Custom-Butted 6066 Aluminum, Tapered Head Tube, BB92 Press-Fit Bottom Bracket, Sealed Cartridge Bearing Pivots
Suspension Fork
Rock Shox Recon Silver 29, 1.5" Taper Steerer, PushLoc Remote, 15mm Maxle, 120mm Travel
Rear Shock
Rock Shox Monarch R, 120mm Travel
Drivetrain
Rear Derailleur
Shimano SLX 10-Speed, SGS, Shadow Plus Design
Front Derailleur
Shimano Deore 10-Speed, Direct Mount
Shift Levers
Shimano Deore 20-Speed
Cassette
Shimano HG-50 10-Speed, 11-36T
Crank
Shimano Deore 10-Speed, 2-Piece Design, 36-22T
Bottom Bracket
Shimano BB92 press-fit Bearing System
Chain
KMC X10, 10-Speed
Pedals
na
Wheels
Rims
Shimano Deore, 32H 15mm Thru-Axle, CenterLock Front / Shimano Deore 32H CenterLock Rear, WTB STP i23 TCS 29" Rims (Tubeless-Ready)
Tires
WTB Trailboss 29x2.25" Comp
Brakes
Brakes
Shimano M447 Hydraulic Disc Brake, 180mm Front, 160mm Rear
Brake Levers
Shimano M506 Hydraulic Disc Brake
Cockpit
Stem
Race Face Ride, 3D-Forged 6061 Aluminum, 31.8, 6° Rise
Handlebar
Race Face Ride Low Riser, 31.8, 10mm Rise, 5° Sweep
Headset
FSA 1 1/8"-1 1/2", Fully Integrated, 36° ACB-Sealed, 7.8mm Aluminum Top Cover
Seat
Saddle
WTB Volt, Satin Steel Rail
Seatpost
RaceFace Ride, 6061 Aluminum, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.41 mm | 1.41 mm | 1.39 mm |
| Bottom Bracket Height | 336 mm | 336 mm | 336 mm | 336 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Stack | 594.9 mm | 604.3 mm | 613.7 mm | 623 mm |
| Reach | 414.9 mm | 427.3 mm | 434.6 mm | 447.1 mm |
| Top Tube Length | 581 mm | 596 mm | 606 mm | 621 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 430 mm | 470 mm | 500 mm | 530 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1123 mm | 1139 mm | 1150 mm | 1166 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 761 mm | 761 mm | 764 mm | 771 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Supercell 29 Expert belongs to the Breezer Supercell model. There are 17 bikes that carry this model name. Take a sneak peek at all Breezer Supercell bikes models from 2016, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
As for the rear shock, this bike has the Rock Shox Monarch R model, with a travel of 120mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
As for the wheels, Breezer Supercell 29 Expert 2016, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Breezer Supercell 29 Expert has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Supercell 29 Expert comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
