Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Factory Float 34
-
Groupset XT -
Suspension Full -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Breezer D'Fusion Hydroformed Custom-Butted 6066 Aluminum, Tapered Head Tube, BB92 Press-Fit Bottom Bracket, Sealed Cartridge Bearing Pivots
Suspension Fork
Fox 34 Float Factory 29 FIT4, 3-Position, Kashima Coat, 1.5" Taper Steerer, 15QR Axle, Lockout, 120mm Travel
Rear Shock
Fox Float 3-Position, Kashima Coat, 120mm Travel
Drivetrain
Rear Derailleur
Shimano Deore XT 11-Speed
Front Derailleur
Shimano Deore XT 11-Speed, Direct Mount
Shift Levers
Shimano Deore XT 22-Speed
Cassette
Shimano Deore XT 11-Speed, 11-40T
Crank
Shimano Deore XT 11-Speed, Hollowtech II, 36-26T
Bottom Bracket
Shimano BB92 press-fit Bearing System
Chain
KMC X11L, 11-Speed
Pedals
na
Wheels
Rims
Shimano Deore XT 15mm Thru-Axle 32H CenterLock Front / Shimano Deore XT 12mm Thru-Axle 32H CenterLock Rear, WTB Frequency Race i23 TCS 29" Rims (Tubeless-Ready)
Tires
WTB Trailboss 29x2.25" TCS Lite Fast
Brakes
Brakes
Shimano Deore XT Hydraulic Disc Brake, 180mm Front, 160mm Rear
Brake Levers
Shimano Deore XT Hydraulic Disc Brake
Cockpit
Stem
Race Face Turbine Basic, 7050 Aluminum, 6° Rise
Handlebar
Race Face Evolve Low Riser, 31.8, 10mm Rise, 5° Sweep
Headset
FSA 1 1/8"-1 1/2", Fully Integrated, 36° ACB-Sealed, 7.8mm Aluminum Top Cover
Seat
Saddle
WTB Volt Race, Ti/Cro Tubular Rail
Seatpost
RaceFace Ride, 6061 Aluminum, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.41 mm | 1.41 mm | 1.39 mm |
| Bottom Bracket Height | 336 mm | 336 mm | 336 mm | 336 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Stack | 594.9 mm | 604.3 mm | 613.7 mm | 623 mm |
| Reach | 414.9 mm | 427.3 mm | 434.6 mm | 447.1 mm |
| Top Tube Length | 581 mm | 596 mm | 606 mm | 621 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 430 mm | 470 mm | 500 mm | 530 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1123 mm | 1139 mm | 1150 mm | 1166 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 761 mm | 761 mm | 764 mm | 771 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Supercell 29 Team is part of the Breezer Supercell model. Breezer released 17 bikes variations of this model so far. Take a sneak peek at all Breezer Supercell bikes models from 2016, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
This bike has the Fox Factory Float 34 fork installed. The fork’s travel is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the Fox Float 3-Position rear shock model, which has a travel of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The wheels on Supercell 29 Team are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Supercell 29 Team comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Supercell 29 Team comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
