Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork X Fusion
-
Groupset XT, Deore -
Suspension Full -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Breezer D'Fusion Hydroformed Custom-Butted 6066 Aluminum, Tapered Head Tube, BB92 Press-Fit Bottom Bracket, Sealed Cartridge Bearing Pivots
Suspension Fork
X-Fusion Slide 29 RL2, 1.5" Taper Steerer, LockX 15mm Axle, Lockout, 120mm Travel
Rear Shock
X-Fusion O2 RL, 120mm Travel
Drivetrain
Rear Derailleur
Shimano Deore XT 10-Speed, SGS, Shadow Plus Design
Front Derailleur
Shimano Deore 10-Speed, Direct Mount
Shift Levers
Shimano Deore 30-Speed
Cassette
Shimano HG-50 10-Speed, 11-36T
Crank
Shimano M612 10-Speed, 40-30-22T
Bottom Bracket
Shimano BB92 Press-Fit Bearing System
Chain
KMC X10
Pedals
-
Wheels
Rims
Shimano M4050 32H CenterLock Hubs, WTB SX19 29" Rims
Tires
WTB Trail Boss 29x2.25" Comp
Brakes
Brakes
Shimano M447 Hydraulic Disc Brake, 180mm Front, 160mm Rear
Brake Levers
Shimano M445 Hydraulic Disc Brake
Cockpit
Stem
Oval Concepts 313, 3D-Forged 6061 Aluminum, 31.8, 7°/83°
Handlebar
Oval Concepts 250, 6061 Aluminum, 31.8, 710mm Wide, +/- 5mm Rise, 9° Sweep
Headset
FSA Orbit 1 1/8"-1 1/2", Fully Integrated, 36° ACB-Sealed, 7.8mm Aluminum Top Cover
Seat
Saddle
WTB Volt, Satin Steel Rail
Seatpost
Oval Concepts 300, 3D-Forged 6061 Aluminum, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.41 mm | 1.41 mm | 1.39 mm |
| Bottom Bracket Height | 336 mm | 336 mm | 336 mm | 336 mm |
| Front Center | 680.3 mm | 696.1 mm | 706.8 mm | 722.7 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Stack | 594.9 mm | 604.3 mm | 613.7 mm | 623 mm |
| Reach | 414.9 mm | 427.3 mm | 434.6 mm | 447.1 mm |
| Top Tube Length | 581 mm | 596 mm | 606 mm | 621 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 430 mm | 470 mm | 500 mm | 530 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1123 mm | 1139 mm | 1150 mm | 1166 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 761 mm | 761 mm | 764 mm | 771 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Supercell Expert is part of the Breezer Supercell model. Breezer released 17 bikes variations of this model so far. Take a sneak peek at all Breezer Supercell bikes models from 2015, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Trail bikes
The average weight for Trail bikes is 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Supercell Expert weighs 15.1 kg (33.29 lbs) and is much heavier than the average. In conclusion, the average Trail bike weighs 16.33% less than Supercell Expert.
Supercell Expert components
Fork
The Supercell Expert comes factory-installed with the X Fusion fork. This has a travel range of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
As for the rear shock, this bike has the X-Fusion O2 RL model, with a travel of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When leaving the production line, the Supercell Expert model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Breezer Supercell Expert is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
