BULLS Cross Flyer EVO Diamond 2023
2023 E-bike
Estimate price |
3,898$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour NVX
-
Groupset Alivio, FSA -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTube Horizontal 500 -
Drivetrain 1 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy
Suspension Fork
Suntour NVX 30 NLO DS QR 700C STEEL TAPERED
Drivetrain
Rear Derailleur
SHIMANO Alivio RD-M3100-SGS Shadow
Shift Levers
SHIMANO Alivio SL-M3100
Cassette
SHIMANO Altus CS-HG200-9 11-36T
Crank
FSA 170mm
Chain
KMC E9S
Pedals
wellgo C-098DU black body
Wheels
Front Hub
FORMULA DC-20QR
Rear Hub
FORMULA DC-22QR
Rims
STYX DDM-2
Tires
SCHWALBE Smart Sam Performance
Brakes
Brakes
hydraulic disc brake
Brake Levers
TEKTRO MD-M280
Cockpit
Stem
MTB-SL, CCS Slot Mount ready
Handlebar
STYX
Headset
FSA no.57 B-1
Seat
Saddle
BULLS Sportive Ergo
Seatpost
STYX, 10mm Offset
Motor & Battery
Motor
Bosch Performance Line CX 25/85 Nm
Battery
Bosch PowerTube Horizontal 500
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 50cm | 55cm | 60cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.66 mm | 1.69 mm | 1.72 mm | 1.74 mm |
| Front Center | 678 mm | 689 mm | 699 mm | 711 mm |
| Rake | 38 mm | 37 mm | 36 mm | 36 mm |
| Trail | 93 mm | 94 mm | 95 mm | 95 mm |
| Stack | 667 mm | 686 mm | 704 mm | 723 mm |
| Reach | 401 mm | 406 mm | 410 mm | 415 mm |
| Top Tube Length | 599 mm | 609 mm | 619 mm | 629 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm | 600 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 459 mm | 459 mm | 459 mm | 459 mm |
| Wheelbase | 1129 mm | 1140 mm | 1150 mm | 1162 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
Cross Flyer EVO Diamond is a Bulls E Cross model. There are 83 e-bikes that carry this model name. Take a sneak peek at all Bulls E Cross e-bikes models from 2023, by clicking here.
Model range prices
Bulls Cross Flyer EVO Diamond 2023 is the cheapest e-bike model and costs 3609$. Bulls Cross Lite EVO 3 Wave 2023 is the most expensive one and costs 5520$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Hybrid e-bikes average price
If you want an acceptable Hybrid e-bike you should know that the average price is 2480$. However, you could also get a good Hybrid e-bike even if you pay a lower amount than the average price. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
At the moment of the release date, Bulls Cross Flyer EVO Diamond price was 3609$. If we compare this with the average Hybrid e-bike cost we notice that the price is 45.52% more expensive.
Cross Flyer EVO Diamond components
Fork
The fork installed on this bike is the Suntour NVX model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork on this e-bike is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
As for the wheels, Bulls Cross Flyer EVO Diamond 2023, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Cross Flyer EVO Diamond comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
