Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Fork RockShox Recon Silver RL
-
Groupset SRAM, NX -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 hydroformed alloy, tapered headtube
Suspension Fork
Rock Shox Recon RL Boost 29", 130mm travel, 15 x 110mm axle, tapered steerer, Fast black stanchions.
Drivetrain
Rear Derailleur
SRAM NX11 Speed, long cage
Shift Levers
SRAM NX
Cassette
Sunrace 11 spd
Crank
Samox 2pc Alloy, 170mm legs
Bottom Bracket
Power spline
Pedals
Black alloy platform
Wheels
Front Hub
Formula boost, bolt through, 15 x 110mm, 32h, 6 bolt.
Rear Hub
Formula bolt through, 32h
Rims
Calibre 29" alloy disc rims
Tires
WTB Trailboss G2
Brakes
Brakes
SRAM Guide T
Cockpit
Stem
Calibre 45mm alloy
Handlebar
Calibre, 31.8 O.D, 780mm wide, 30mm rise.
Headset
FSA, No57 Orbit 1.5E Zs
Seat
Saddle
Calibre trail
Seatpost
KS Rage-I dropper, 30.9mm, 125mm travel, Southpaw remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm |
| Top Tube Length | 602 mm | 615 mm | 645 mm | 675 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 415 mm | 425 mm | 465 mm | 480 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Line 29 is part of the Calibre Line model. 12 bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Trail bikes average weight
If we make a quick analysis of the average weight of a Trail bike, we get 12.98 kg (28.62 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 14 kg (30.86 lbs), the Line 29 model is a bit heavier than average. In short, the average Trail bike weight is 7.86% lower than this one.
Overview of components
Fork
This bike has the RockShox Recon Silver RL fork installed. The fork’s travel is 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When leaving the production line, the Line 29 model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The Line 29 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Calibre Line 29 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Calibre Line 29 includes a dropper post. Therefore, climbing or descending will be a breeze.
