Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox Yari RC
-
Groupset NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29” 6061 Alloy, 150mm rear wheel travel, 148 x 12mm bolt through
Suspension Fork
Rock Shox Yari RC, 160mm travel, 42mm fork offset
Rear Shock
Rock Shox Deluxe R, custom tuned, 230 x 62.5mm
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM NX Eagle
Cassette
SRAM NX Eagle
Crank
SRAM NX Eagle Power spline 32T
Pedals
Alloy platform test pedals
Wheels
Front Hub
Formula Boost, bolt through, sealed bearings
Rear Hub
Formula Boost, bolt through, sealed bearings
Rims
29” WTB ST i29 TCS 2.0 32H Tubeless ready
Tires
Front: WTB Vigilante TCS G2 Tough High Grip 2.6”, Rear: WTB Vigilante TCS G2 Tough High Grip 2.6”
Brakes
Brakes
SRAM Guide RE, 200mm front, 180mm rear rotor
Cockpit
Stem
Calibre Trail 45mm
Handlebar
Kore Durox 800mm width 20mm rise
Headset
FSA Orbit tapered No. 57E
Seat
Saddle
Calibre Sentry
Seatpost
Kore Mega stealth 150mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Front Center | 775 mm | 797 mm | 820 mm | 842 mm |
| Seat Tube Angle | 76.2 ° | 76 ° | 76 ° | 75.8 ° |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 97 mm | 102 mm | 102 mm | 102 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1218 mm | 1240 mm | 1263 mm | 1285 mm |
| Bottom Bracket Drop | 34 mm | 34 mm | 34 mm | 34 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
SENTRY is a Calibre Sentry model. Calibre released 6 bikes variations of this model so far. You can easily view all of the Calibre Sentry bikes models from 2022, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Enduro bikes average price
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Enduro bikes average weight
Enduro bikes weigh an average of 14.27 kg (31.46 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
considerably heavier than average, SENTRY has a weight of 16.2 kg (35.71 lbs). In short, the average Enduro bike weight is 13.52% lower than this one.
Overview of components
Fork
The fork installed on this bike is the RockShox Yari RC model. The travel on this model is 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is Rock Shox Deluxe R, with a travel distance of 150mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The wheels on SENTRY are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. Calibre SENTRY has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
SENTRY comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Calibre SENTRY comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
