Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox Yari RC
-
Groupset NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29” 6061 Alloy, 150mm rear wheel travel, 148 x 12mm bolt through
Suspension Fork
Rock Shox Yari RC, 160mm travel, 42mm fork offset
Rear Shock
Rock Shox Deluxe R, custom tuned, 230 x 62.5mm
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM NX Eagle
Cassette
SRAM NX Eagle
Crank
SRAM NX Eagle Power spline 32T
Pedals
Alloy platform test pedals
Wheels
Front Hub
Formula Boost, bolt through, sealed bearings
Rear Hub
Formula Boost, bolt through, sealed bearings
Rims
29” WTB ST i29 TCS 2.0 32H Tubeless ready
Tires
Front: WTB Vigilante TCS G2 Tough High Grip 2.6”, Rear: WTB Vigilante TCS G2 Tough High Grip 2.6”
Brakes
Brakes
SRAM Guide RE, 200mm front, 180mm rear rotor
Cockpit
Stem
Calibre Trail 45mm
Handlebar
Kore Durox 800mm width 20mm rise
Headset
FSA Orbit tapered No. 57E
Seat
Saddle
Calibre Sentry
Seatpost
Kore Mega stealth 150mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Front Center | 775 mm | 797 mm | 820 mm | 842 mm |
| Seat Tube Angle | 76.2 ° | 76 ° | 76 ° | 75.8 ° |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 97 mm | 102 mm | 102 mm | 102 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1218 mm | 1240 mm | 1263 mm | 1285 mm |
| Bottom Bracket Drop | 34 mm | 34 mm | 34 mm | 34 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
SENTRY completes the Calibre Sentry model. 6 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Enduro bikes
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Enduro bikes
Enduro bikes have an average weight of 14 kg (30.86 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Calibre SENTRY it’s weighing 16.2 kg (35.71 lbs). At this weight, is much heavier than average. In conclusion, the average Enduro bike weighs 15.71% less than SENTRY.
SENTRY components
Fork
This bike has the RockShox Yari RC fork installed. The fork’s travel is 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
From the factory, it comes with the Rock Shox Deluxe R rear shock model, which has a travel of 150mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
As for the wheels, Calibre SENTRY 2023, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. Calibre SENTRY has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the SENTRY. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
