Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 130mm -
Fork RockShox Revelation RC
-
Groupset SLX -
Suspension Full -
Motor Bosch 250W 75Nm mid-drive -
Battery BOSCH PowerPack -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Revelation RC 27.5+ Solo Air, 110mm boost spacing
Rear Shock
RockShox Monarch R Debonair
Drivetrain
Rear Derailleur
Shimano SLX M7000 Shadow Plus, 11-speed
Front Derailleur
N/A
Shift Levers
Shimano SLX M-7000, 11-speed
Cassette
Sunrace CSMS2 11-42 tooth
Crank
Cannondale EC3, Ai offset ring
Bottom Bracket
Cannondale AI, 83mm, press-fit
Chain
Shimano HG601, 11-speed
Chain Guide
Top guide
Pedals
N/A
Wheels
Front Hub
Formula Disc, 15mm x 110mm quick release front, 12mm x 157mm rear
Rear Hub
Formula Disc, 15mm x 110mm quick release front, 12mm x 157mm rear
Rims
WTB I45, 40mm inner width, tubeless ready
Spokes
32 count front and rear
Tires
Schwalbe Nobby Nic 2.8", Snakeskin casing, folding bead, tubeless ready
Brakes
Brakes
Shimano SLX, 200mm front / 180mm rear rotors
Brake Levers
Shimano SLX
Cockpit
Stem
Cannondale C3 alloy, 55mm length
Handlebar
Cannondale C2 alloy, 780mm width, 15mm rise
Grips
Cannondale, lock-on
Headset
Tange Seiki
Seat
Saddle
Fabric Scoop Elite
Seatpost
KS Lev Integra, S - 125mm travel, M/L/XL - 150mm travel
Motor & Battery
Motor
BOSCH Performance CX 250W
Battery
BOSCH PowerPack
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.444 mm | 1.44 mm | 1.378 mm | 1.301 mm |
| Bottom Bracket Height | 347 mm | 347 mm | 347 mm | 347 mm |
| Stack | 598 mm | 612 mm | 623 mm | 623 mm |
| Reach | 414 mm | 425 mm | 452 mm | 479 mm |
| Top Tube Length | 574 mm | 601 mm | 631 mm | 658 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 67 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 109.7 mm | 122.4 mm | 134.4 mm | 134.4 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1172 mm | 1183 mm | 1214 mm | 1241 mm |
| Bottom Bracket Drop | 8 mm | 8 mm | 8 mm | 8 mm |
| Standover Height | 747 mm | 758 mm | 762 mm | 765 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Moterra 2 belongs to the Cannondale E Moterra model. 55 e-bikes variations carry this model name so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Cannondale Moterra 2018 is the cheapest e-bike model and costs 5499$. Cannondale Moterra SE 2018 is the most expensive one and costs 5999$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail e-bikes average price
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Moterra 2 components
Fork
Cannondale Moterra 2 2018 e-bike is equipped with the RockShox Revelation RC fork, and has 130mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
As for the rear shock, this e-bike has the RockShox Monarch R Debonair model, with a travel of 130mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, Cannondale Moterra 2 2018, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Moterra 2 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Cannondale Moterra 2 includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
