Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 160mm -
Fork Fox Factory Float 36
-
Groupset XT -
Suspension Full -
Motor Bosch 250W 75Nm mid-drive -
Battery BOSCH PowerPack -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX 36 Factory Float FIT4 damper, Kashima coating, 3 position compression adjustment
Rear Shock
FOX Factory Float DPS, EVOL air canister, Kashima coated
Drivetrain
Rear Derailleur
Shimano XT M-8000 Shadow Plus, 11-speed
Front Derailleur
N/A
Shift Levers
Shimano XT, I-Spec, 11-speed
Cassette
Shimano SLX CS-M7000, 11-42 tooth
Crank
Cannondale EC3, Ai offset ring
Bottom Bracket
Cannondale AI, 83mm, press-fit
Chain
Shimano HG601, 11-speed
Chain Guide
Top guide
Pedals
N/A
Wheels
Front Hub
Formula Disc, 15mm x 110mm quick release front, 12mm x 157mm rear
Rear Hub
Formula Disc, 15mm x 110mm quick release front, 12mm x 157mm rear
Rims
DT Swiss XM481, 30mm inner width, tubeless ready
Spokes
32 count front and rear
Tires
Front: Schwalbe Magic Mary 2.35", Super Gravity casing, tubeless ready, Rear: Schwalbe Hans Dampf 2.35", Super Gravity casing, tubeless ready
Brakes
Brakes
Shimano XT, 200mm front / 180mm rear rotors
Brake Levers
Shimano XT
Cockpit
Stem
FSA Gravity Light, 45mm length
Handlebar
Cannondale C2 alloy, 780mm width, 15mm rise
Grips
Cannondale, lock-on
Headset
Tange Seiki
Seat
Saddle
Fabric Scoop Elite
Seatpost
KS Lev Integra, S - 125mm travel, M/L/XL - 150mm travel
Motor & Battery
Motor
BOSCH Performance CX 250W
Battery
BOSCH PowerPack
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.485 mm | 1.418 mm | 1.358 mm | 1.281 mm |
| Bottom Bracket Height | 357 mm | 357 mm | 357 mm | 357 mm |
| Stack | 588 mm | 600 mm | 611 mm | 611 mm |
| Reach | 396 mm | 423 mm | 450 mm | 477 mm |
| Top Tube Length | 556 mm | 586 mm | 616 mm | 643 mm |
| Seat Tube Angle | 74.8 ° | 74.8 ° | 74.8 ° | 74.8 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 109.7 mm | 122.4 mm | 134.4 mm | 134.4 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1157 mm | 1189 mm | 1221 mm | 1248 mm |
| Bottom Bracket Drop | -2 mm | -2 mm | -2 mm | -2 mm |
| Standover Height | 770 mm | 780 mm | 780 mm | 790 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Moterra LT 1 is part of the Cannondale E Moterra model. Cannondale launched 55 e-bikes of this model so far. You can easily view all of the Cannondale E Moterra e-bikes models from 2018, here.
Model range prices
Cannondale Moterra 2018 is the cheapest e-bike model and costs 5499$. Cannondale Moterra SE 2018 is the most expensive one and costs 5999$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro e-bikes
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Moterra LT 1 components
Fork
Cannondale Moterra LT 1 2018 e-bike is equipped with the Fox Factory Float 36 fork, and has 160mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Cannondale Moterra LT 1 e-bike has the FOX Factory Float DPS model installed, and has a travel of 160mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
As for the wheels, Cannondale Moterra LT 1 2018, has a 27.5″ aluminum model. These wheels will provide you with more control over the e-bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Cannondale Moterra LT 1 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
