Cannondale Moterra Neo Carbon SE 2021
2021 E-bike
Estimate price |
9,635$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 180mm -
Travel Rear 160mm -
Fork RockShox BoXXer Select
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Motor Bosch -
Battery Bosch PowerTube 625Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 165cm
MD
167cm - 175cm
LG
172cm - 182cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
160mm travel, BallisTec Carbon Front Triangle, SmartForm C1 Alloy Swingarm, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, Ai offset drivetrain, internal cable routing, 148x12mm thru-axle, post mount brake, tapered headtube
Suspension Fork
RockShox Boxxer Select Charger RC, 180mm, DebonAir, 20x110, 56mm offset
Rear Shock
RockShox Super Deluxe Select
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM NX Eagle, single click, 12-speed
Cassette
SRAM XG-1275 Eagle, 10-52, 12-speed
Crank
FSA Bosch E-bike w/ custom Ai offset, 160mm, 34T
Bottom Bracket
Cannondale AI, 83mm, press-fit
Chain
SRAM NX Eagle, 12-speed
Pedals
Not included
Wheels
Front Hub
Formula 20x110mm Boost
Rear Hub
SRAM MTH 700, 12 x 148, XD Driver
Rims
WTB KOM Trail i30 TCS, 32h, tubeless ready
Spokes
DT Swiss Champion
Tires
Maxxis Assegai, 27.5/29 x 2.5", Dual compound, EXO puncture protection, tubeless ready
Brakes
Brakes
SRAM Code R hydraulic disc, 4-piston, CenterLine 200/200mm rotors
Brake Levers
SRAM Code R hydraulic disc
Cockpit
Stem
Cannondale 1, 3D Forged 6061 Alloy, 1-1/8", 31.8, 7°
Handlebar
Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 780mm
Grips
Fabric FunGuy
Headset
Integrated Sealed Bearing, Tapered
Seat
Saddle
Fabric Scoop Shallow Sport, steel rails
Seatpost
Cannondale DownLow Dropper, internal routing, 31.6, 100mm (S), 125mm (M), 150mm (L/XL)
Motor & Battery
Motor
Bosch PowerTube 625Wh
Battery
Bosch PowerTube 625Wh
Remote
Bosch Purion
Charger
Bosch 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.444 mm | 1.44 mm | 1.378 mm | 1.301 mm |
| Bottom Bracket Height | 355 mm | 355 mm | 355 mm | 355 mm |
| Front Center | 725 mm | 746 mm | 771 mm | 801 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 111 mm | 107 mm | 107 mm | 107 mm |
| Stack | 598 mm | 612 mm | 623 mm | 623 mm |
| Reach | 414 mm | 425 mm | 452 mm | 479 mm |
| Top Tube Length | 574 mm | 601 mm | 631 mm | 658 mm |
| Seat Tube Angle | 74.8 ° | 73.9 ° | 73.9 ° | 73.9 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 66.5 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 110 mm | 122 mm | 134 mm | 134 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1170 mm | 1191 mm | 1216 mm | 1245 mm |
| Standover Height | 751 mm | 761 mm | 765 mm | 768 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 157 cm | 167 cm | 172 cm | 185 cm |
| Rider Max Height | 165 cm | 175 cm | 182 cm | 195 cm |
About this model
Moterra Neo Carbon SE belongs to the Cannondale E Moterra model. Cannondale launched 55 e-bikes of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Cannondale Moterra Neo 5 + 2021 is the cheapest e-bike model and costs 4246$. Cannondale Moterra Neo Carbon 1 2021 is the most expensive one and costs 9343$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro e-bikes average price
If you want to purchase a solid Enduro e-bike, it is important to know that the average cost is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2021 for 8758$. Comparing this to the average Enduro e-bike price, we see that the price is 83.03% more expensive.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Moterra Neo Carbon SE components
Fork
This e-bike has the RockShox BoXXer Select fork installed. The fork’s travel is 180mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
From the factory, it comes with the RockShox Super Deluxe Select rear shock model, which has a travel of 160mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The wheels on Moterra Neo Carbon SE are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Moterra Neo Carbon SE comes in 4 sizes, that range from 157 cm – 195 cm (5.15 ft – 6.4 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
