Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork RockShox SID Select
-
Groupset NX Eagle, Truvativ Stylo -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 165cm
MD
167cm - 175cm
LG
172cm - 182cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SmartForm C1 Alloy, 100mm travel, Zero Pivot seatstay, Carbon Link, PF30-83, 1.5 Si head tube, Ai Offset
Suspension Fork
RockShox SID Select, 100mm, Debonair, 15x110, tapered steerer, 42/51mm offset
Rear Shock
RockShox Monarch RL
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM NX Eagle, 12-speed
Cassette
SRAM PG-1230, NX Eagle, 11-50, 12-speed
Crank
Truvativ Stylo 6K DUB, 34T, Ai offset
Bottom Bracket
SRAM DUB PF30 MTB83
Chain
SRAM NX Eagle, 12-speed
Pedals
Not Included
Wheels
Front Hub
Lefty 60
Rear Hub
Formula 12x142mm w/ HG driver
Rims
WTB STX i21 TCS, 28h, tubeless ready
Spokes
DT Swiss Competition (Ai Offset dish - rear)
Tires
Schwalbe Racing Ray Performance 27.5/29x2.25", Addix Compound, tubeless readySchwalbe Racing Ralph Performance 27.5/29x2.25", Addix Compound, tubeless ready
Brakes
Brakes
Shimano MT500 hydraulic disc, 180/160mm RT56 rotors
Brake Levers
Shimano MT500 hydraulic disc
Cockpit
Stem
Cannondale 3, 6061 Alloy, 31.8, 7°
Handlebar
Cannondale 3 Flat, 6061 double-butted Alloy, 31.8mm, 3° rise, 8° sweep, 760mm
Grips
Cannondale Locking Grips
Headset
Integrated, 1-1/8 to 1.5", sealed angular contact bearings (Integrated steer stop size small only)
Seat
Saddle
Fabric Scoop Shallow Sport, steel rails
Seatpost
Cannondale 3, 6061 Alloy, 31.6x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.421 mm | 1.478 mm | 1.437 mm | 1.393 mm |
| Bottom Bracket Height | 343 mm | 345 mm | 345 mm | 345 mm |
| Front Center | 656 mm | 690 mm | 715 mm | 741 mm |
| Rake | 44 mm | 51 mm | 51 mm | 51 mm |
| Trail | 91 mm | 92 mm | 92 mm | 92 mm |
| Stack | 560 mm | 603 mm | 615 mm | 627 mm |
| Reach | 394 mm | 408 mm | 428 mm | 450 mm |
| Top Tube Length | 574 mm | 604 mm | 627 mm | 653 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 97 mm | 110 mm | 122 mm | 134 mm |
| Chainstay Length | 426 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1082 mm | 1125 mm | 1149 mm | 1176 mm |
| Bottom Bracket Drop | 10 mm | 27 mm | 27 mm | 27 mm |
| Standover Height | 791 mm | 835 mm | 863 mm | 891 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 157 cm | 167 cm | 172 cm | 185 cm |
| Rider Max Height | 165 cm | 175 cm | 182 cm | 195 cm |
About this model
Scalpel-Si 5 is a Cannondale Scalpel Si model. There are 69 bikes that carry this model name. You can easily view all of the Cannondale Scalpel Si bikes models from 2023, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
The RockShox SID Select is included from the factory. It has a travel distance of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The Scalpel-Si 5 has a rear shock with a travel of 100mm. The model RockShox Monarch RL is the one installed in this bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The Scalpel-Si 5 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Cannondale Scalpel-Si 5 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 157 cm – 195 cm (5.15 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
