Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork RockShox Judy Silver TK
-
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
137cm - 157cm
SM
154cm - 164cm
MD
161cm - 172cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SmartForm C2 Alloy, SAVE, Boost spacing, tapered 1-1/8" to 1.5" headtube, flat mount brake, StraightShot internal cable routing, BSA-73
Suspension Fork
RockShox Judy Silver TK, 120mm, Solo Air, 15x110, tapered steerer, 42mm offset
Drivetrain
Rear Derailleur
SRAM SX Eagle
Shift Levers
SRAM SX Eagle, 12-speed
Cassette
SRAM PG-1210, SX Eagle, 11-50, 12-speed
Crank
SRAM SX Eagle, 30T
Bottom Bracket
Truvativ Power Spline
Chain
SRAM SX Eagle, 12-speed
Pedals
Cannondale Platform
Wheels
Front Hub
Shimano MT400 15x110
Rear Hub
Shimano MT200, Boost 141, QR
Rims
WTB STX i23 TCS, 32h, tubeless ready
Spokes
Stainless Steel, 14g
Tires
WTB Breakout Comp, 27.5/29 x 2.3", DNA Compound
Brakes
Brakes
Shimano MT200 hydro disc, 180/160mm RT10 rotors
Brake Levers
Shimano MT200 hydro disc
Cockpit
Stem
Cannondale 3 with Intellimount, alloy, 31.8mm clamp
Handlebar
Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 740mm
Grips
Cannondale Low-Profile Locking Grips
Headset
Semi Integrated, 1-1/8" reducer
Seat
Saddle
Cannondale Stage 3 Women's Ergo
Seatpost
6061 Alloy, 31.6 x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.56 mm | 1.48 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm |
| Front Center | 635 mm | 661 mm | 686 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 102 mm | 102 mm | 102 mm |
| Stack | 598 mm | 603 mm | 607 mm |
| Reach | 363 mm | 386 mm | 410 mm |
| Top Tube Length | 541 mm | 566 mm | 591 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 345 mm | 385 mm | 420 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 100 mm | 105 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1066 mm | 1091 mm | 1117 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm |
| Standover Height | 650 | 677 mm | 696 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 137 cm | 154 cm | 161 cm |
| Rider Max Height | 157 cm | 164 cm | 172 cm |
About this model
Tango 1 belongs to the Cannondale Tango model. 27 bikes variations carry this model name so far. Take a sneak peek at all Cannondale Tango bikes models from 2022, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Tango 1 components
Fork
Cannondale Tango 1 2022 bike is equipped with the RockShox Judy Silver TK fork, and has 120mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When leaving the production line, the Tango 1 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Tango 1 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 137 cm – 172 cm (4.49 ft – 5.64 ft). In conclusion, you won’t have a problem finding one that suits you.
