Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Acera, Altus -
Suspension Hardtail -
Motor Bosch 250W 50Nm mid-drive -
Battery Bosch PowerPack 400Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 175cm
MD
177cm - 192cm
LG
189cm - 203cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tesoro Neo, SmartForm C2 Alloy
Suspension Fork
SR Suntour NEX HLO E25 DS, 63mm, tapered steerer
Drivetrain
Rear Derailleur
Shimano Acera M3000
Shift Levers
Shimano Altus M2000, 1x9
Cassette
Shimano HG200, 11-34, 9-speed
Crank
FSA E-bike, 170mm, Gen3, 38t
Chain
KMC X9, 9-speed
Pedals
Cannondale Urban Pedal
Wheels
Front Hub
(F) Shimano HB-TX505, 100x9mm QR front
Rear Hub
(R) Shimano HB-TX505, 135x9mm QR
Rims
Cannondale C2, Double wall
Spokes
DT Swiss Champion
Tires
Schwalbe Little Big Ben, 700x38c, K-Guard puncture protection, reflective sidewalls
Brakes
Brakes
Shimano MT200 hydro disc, 180/160mm RT10 rotors
Brake Levers
Shimano MT200 hydro disc
Cockpit
Stem
Cannondale C3, 6061 Alloy, 31.8, 7°, 100mm
Handlebar
Cannondale E-Series Alloy, backsweep, 660mm
Grips
Cannondale Ergo
Headset
Tange Seiki integrated, 1-1/8 to 1.5"
Seat
Saddle
Cannondale Ergo Performance
Seatpost
Cannondale C3, 6061 Alloy, 31.6x300mm
Motor & Battery
Motor
Bosch Active Line Plus 250W
Battery
Bosch PowerPack 400Wh
Charger
Bosch 2A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 177 cm | 189 cm |
| Rider Max Height | 175 cm | 192 cm | 203 cm |
About this model
Tesoro Neo is a Cannondale E Tesoro model. There are 49 e-bikes that carry this model name. You can easily view all of the Cannondale E Tesoro e-bikes models from 2022, here.
Model range prices
Cannondale Tesoro Neo SL EQ Remixte 2022 is the most affordable e-bike of this model and has a price of 2760$. On the other hand, Cannondale Tesoro Neo X Speed 2022, is the most expensive and costs 5500$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Commuter e-bikes
According to our math, the average price for a trustworthy Commuter e-bike is 2569$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
The fork installed on this bike is the Suntour NEX model. The travel on this model is 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The wheels on Tesoro Neo are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Tesoro Neo comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 3 sizes. They vary from 162 cm – 203 cm (5.31 ft – 6.66 ft). In short, it won’t be difficult to find the right one for you.
