Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Trail, SmartForm C2 Alloy, SAVE, 1-1/8??? head tube
Suspension Fork
SR Suntour XCM-RL, 100mm, remote lockout, 1-1/8", 29"/27.5", Coil
Drivetrain
Rear Derailleur
Shimano Alivio, 9-speed
Front Derailleur
Shimano Altus, 31.8 clamp
Shift Levers
Shimano Altus, 3x9 speed
Cassette
Sunrace, 11-34, 9-speed
Crank
Shimano M371, 44/32/22
Bottom Bracket
Tange LN 3912, square taper
Chain
Shimano HG53, 9-speed
Pedals
Cannondale Platform
Wheels
Front Hub
Alloy Disc, sealed, loose ball bearings, QR, 32h
Rear Hub
Alloy Disc, sealed, loose ball bearings, QR, 32h
Rims
Alex DC 4.0, double wall, 32-hole
Spokes
Stainless Steel, 15g Black
Tires
WTB NineLine, 29/27.5x2.0"
Brakes
Brakes
Shimano M315 hydraulic disc, 180/160mm (29"), 160/160mm (27.5")
Brake Levers
Shimano M315 hydraulic disc
Cockpit
Stem
Cannondale Dual-Density
Handlebar
Cannondale C4, 6061 alloy, 20mm rise, 680mm
Grips
Cannondale Dual-Density
Headset
FSA 1-1/8" Semi Integrated
Seat
Saddle
Cannondale Stage 3
Seatpost
Cannondale C3, 6061 alloy, 27.2x350mm
About this model
Trail 5 belongs to the Cannondale Trail model. Cannondale launched 240 bikes of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
Cannondale Trail 16 Single-Speed Girl’s 2017 is the most economical model, with a starting price of 260$. Cannondale Trail 3 2017 on the other hand costs 1080$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2017 for 820$. Comparing the average cost of a Crosscountry bike to this one, you will see that Trail 5 price is 132.32% smaller.
Trail 5 components
Fork
Cannondale Trail 5 2017 bike is equipped with the SunTour XCM fork, and has 100mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The Trail 5 2017 bike is equipped with 27.5″ aluminum wheels when leaving the factory. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Trail 5 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Cannondale Trail 5 2017 is available in one size only. In short, make sure you double-check if it fits you.
