Canyon Exceed CF 8 2023
2023 Mountain
Estimate price |
4,587$
Weight | 10.52 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Fox Factory Float 32
-
Groupset GX Eagle Transmission, X01 Eagle AXS -
Suspension Hardtail -
Battery SRAM Powerpack -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 176cm
MD
174cm - 184cm
LG
182cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Exceed CF, Our superlight, cross-country 29er hardtail gives you race DNA in an accessible carbon package., Axle dimension: 12x148 mm, Material: Carbon (CF)
Suspension Fork
FOX 32 Step-Cast Factory Remote, Axle dimension: 15x110 mm, Stanchion Diameter: 32 mm, Travel: 100 mm, Fork steer tube diameter: 1 1/8" - 1,5", Weight: 1.48 kg
Drivetrain
Rear Derailleur
SRAM GX Eagle AXS Transmission
Shift Levers
SRAM AXS Pod Ultimate
Cassette
SRAM GX Eagle Transmission Cassette 12s 10-52, Number of sprockets: 12 | SRAM XS-1275 T-Type GX 12-speed Cassette 10-52
Crank
SRAM GX Eagle, Number of chainrings: 1
Bottom Bracket
SRAM DUB, Bottom bracket standard: PF 92, Weight: 82 g | SRAM DUB PF41 BB89,5 | BB92 PressFit Bottom Bracket
Chain
SRAM GX Eagle Transmission | SRAM Eagle Transmission PowerLock | SRAM GX T-Type 12-speed Chain 126L
Pedals
None included
Wheels
Rims
DT Swiss XRC 1700 SPLINE, Axle dimension: 12x148 mm, Rotor mount: IS 6-bolt, Weight: 881 g | DT Swiss XRC 1700, Axle dimension: 15x110 mm, Rotor mount: IS 6-bolt, Weight: 791 g
Tires
Maxxis Ikon EXO MaxxSpeed, Width: 2.35"
Brakes
Brakes
SRAM Level Silver Stealth 2 Piston, Number of pistons: 2
Cockpit
Grips
Ergon GA20
Seat
Saddle
Ergon SR10 Pro
Seatpost
Canyon VCLS 2.0, Our light and strong carbon seatpost. The revolutionary, adjustable floating seat clamp lets the saddle tilt so that it's always in contact, even when flexing., Clamp diameter: 30,9 mm, Material: Carbon (CF), Weight: 350 g
Motor & Battery
Battery
SRAM Powerpack
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.45 mm | 1.39 mm | 1.36 mm | 1.34 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm | 316 mm | 316 mm |
| Front Center | 657 mm | 679 mm | 700 | 726 mm | 753 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 89 mm | 89 mm | 89 mm | 89 mm | 89 mm |
| Stack | 589 mm | 589 mm | 594 mm | 608 mm | 626 mm |
| Reach | 384 mm | 407 mm | 427 mm | 447 mm | 467 mm |
| Top Tube Length | 553 mm | 576 mm | 597 mm | 620 mm | 645 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 375 mm | 415 mm | 458 mm | 495 mm | 535 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 90 mm | 90 mm | 95 mm | 110 mm | 130 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 426 mm | 431 mm |
| Wheelbase | 1071 mm | 1094 mm | 1115 mm | 1146 mm | 1178 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 773 mm | 795 mm | 820 mm | 846 mm | 875 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Max Height | 167 cm | 176 cm | 184 cm | 193 cm | cm |
About this model
Exceed CF 8 is part of the Canyon Exceed model. Canyon released 57 bikes variations of this model so far. You can easily view all of the Canyon Exceed bikes models from 2023, here.
Model range prices
The most economical model, the Canyon Exceed CF 4 2023 has a starting price of 1693$. Canyon Exceed CFR LTD 2023 on the other hand is the most expensive at 7599$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4235$. Doing a quick comparison, we notice that Exceed CF 8 price is 122.31% higher than the average cost of a Crosscountry bike.
Crosscountry bikes average weight
If we make a quick analysis of the average weight of a Crosscountry bike, we get 12.4 kg (27.34 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Weighing 10.52 kg (23.19 lbs), the Exceed CF 8 model is much lighter than average. To sum up, it’s 17.87% lighter than the average weight of Crosscountry bikes.
Exceed CF 8 components
Fork
The Exceed CF 8 comes factory-installed with the Fox Factory Float 32 fork. This has a travel range of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The Exceed CF 8 2023 bike is equipped with 29″ carbon wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Canyon Exceed CF 8 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
