Canyon Grail CF SL 7.0 2018
2018 Road
Estimate price |
2,299$
Weight | 8.6 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 650b / 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XXS
157cm - 167cm
XS
165cm - 173cm
SM
171cm - 179cm
MD
177cm - 185cm
LG
183cm - 191cm
XL
188cm - 197cm
XXL
194cm - 204cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Grail CF SL Disc
Suspension Fork
Canyon One One Four SLX, Outstanding handling accuracy guaranteed through high torsional stiffness, Tapered carbon fork shaft: 1 1/2" - 1 1/4", Tube profiles optimised for aero efficiency, Weight: 295 g (with 210 mm fork shaft)
Drivetrain
Rear Derailleur
Shimano 105, 11s, Quick and accurate shifting procedure thanks to a new spring mechanism, Broad gear range, SH RD-5800, 11-speed
Front Derailleur
Shimano 105, 11s, Quick and precise shifting procedures, SH FD-5800, 11-speed
Shift Levers
Shimano 105 Disc, 11s, Hydraulic shift/brake lever, Great brake force, Consistent braking performance in all weather conditions, Grip width adjustment, 11-speed, ST-RS505
Cassette
Shimano 105, 11s, HG-EV 11-Speed Cassette, Stainless steel sprockets, Range: 11-12-13-14-16-18-20-22-25-28-32T, SH CS-5800
Crank
Shimano 105, 11s, Optimised power transmission, Tried and tested four-arm design: stiffer and more lightweight, SH-FC-5800, 11-speed
Bottom Bracket
Shimano Pressfit, Press-Fit, 86,5 x 41mm, SM BB72-41B
Chain
Shimano CN-HG600-11
Pedals
none included
Wheels
Rims
DT Swiss C 1800 Spline DB
Tires
Schwalbe G-ONE Bite
Brakes
Brakes
Shimano 105 Disc, Flat mount, ST-BR 505, Shimano Centerlock disc RT-81, 160 mm brake disk diameter, Framesize 2XS und XS 140 mm
Brake Levers
Shimano 105 Disc, 11s, Hydraulic shift/brake lever, Great brake force, Consistent braking performance in all weather conditions, Grip width adjustment, 11-speed, ST-RS505
Cockpit
Headset
Canyon | Acros
Seat
Saddle
Selle Italia X3 Canyon Edition
Seatpost
Canyon S23 VCLS CF (25 mm Setback), Length: 330 mm, Diameter: 27.2 mm, In-house developed Canyon seatpost with VCLS technology for extra comfort and stability, Setback: 25 mm, Compliant with Canyon Category 2 testing standards
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 432 mm | 462 mm | 492 mm | 522 mm | 552 mm | 582 mm | 612 mm |
| Head Tube Angle | 70.25 ° | 71.25 ° | 71 ° | 72.5 ° | 72.5 ° | 72.75 ° | 72.75 ° |
| Chainstay Length | 413 mm | 413 mm | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 986 mm | 988 mm | 1018 mm | 1027 mm | 1038 mm | 1061 mm | 1071 mm |
| Standover Height | 751 mm | 776 mm | 803 mm | 831 mm | 858 mm | 886 mm | 910 mm |
| Wheels | 650 | 650 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 165 cm | 171 cm | 177 cm | 183 cm | 188 cm | 194 cm |
| Rider Max Height | 167 cm | 173 cm | 179 cm | 185 cm | 191 cm | 197 cm | 204 cm |
Model Overview
Grail CF SL 7.0 belongs to the Canyon Grail model. Canyon launched 90 bikes of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Canyon Grail WMN CF SL 7.0 2018 is the cheapest bike model and costs 2299$. Canyon GRAIL CF SLX 8.0 DI2 2018 is the most expensive one and costs 4899$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Canyon released this model in 2018, its price was 2299$. Comparing this to the average Gravel bike price, we see that the price is 7.09% smaller.
Average weight for Gravel bikes
The average weight for Gravel bikes is 8.13 kg (17.92 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 8.6 kg (18.96 lbs), Canyon bike is a bit heavier than average. To sum up, it’s 5.78% heavier than the average weight of Gravel bikes.
Grail CF SL 7.0 components
Fork material
Grail CF SL 7.0 has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The wheels on Grail CF SL 7.0 are the aluminum type. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Canyon Grail CF SL 7.0 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This bike is available in 7 sizes. They vary from 157 cm – 204 cm (5.15 ft – 6.69 ft). In short, it won’t be difficult to find the right one for you.
