Canyon Grail CF SL 8 2023
2023 Road
Estimate price |
2,899$
Weight | 8.96 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset GRX 800, Rotor -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
165cm - 173cm
SM
171cm - 179cm
MD
177cm - 185cm
LG
183cm - 191cm
XL
189cm - 197cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Grail CF SL Disc, Light, comfortable carbon frame with Gravel Pro geometry., Axle dimension: 12x142 mm, Tyre Clearance: 42 mm, Material: Carbon (CF)
Suspension Fork
Canyon FK0070 CF Disc, A robust carbon fibre fork offering the optimal mix of robustness, stiffness, and lightness., Fork steer tube diameter: 1 1/4", Material: Carbon (CF)
Drivetrain
Rear Derailleur
Shimano GRX RX810 GS, Cage length: long
Front Derailleur
Shimano GRX RX810, Max chainring gear range: 17T.
Shift Levers
Shimano GRX RX810 2s | Shimano GRX RX810, 11-speed
Cassette
Shimano Ultegra HG800 11-34 11s, Number of sprockets: 11
Crank
Rotor Canyon LTD, 48/31, Number of chainrings: 2
Bottom Bracket
Token Ninja Lite BB4124, Bottom bracket standard: PF 86,5
Chain
Shimano CN-HG701 11s
Pedals
None included
Wheels
Rims
DT Swiss G1800 Spline db, Rotor mount: Center Lock, Rim height: 25 mm, Wheelsize: 28" | DT Swiss G1800 Spline db SH11, Rotor mount: Center Lock, Rim height: 25 mm, Wheelsize: 28"
Tires
Schwalbe G-One R, 40mm, Width: 40mm
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano GRX RX810 2s | Shimano GRX RX810, 11-speed
Seat
Saddle
Fizik Argo Terra X5
Seatpost
Canyon S15 VCLS 2.0 CF, Material: Carbon, Setback: 13 mm / 25 mm, Technology: VCLS 2.0 | Fliphead, Weight: 220 g
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.23 mm | 1.26 mm | 1.27 mm | 1.27 mm | 1.33 mm | 1.33 mm | 1.3 mm |
| Front Center | 580 mm | 582 mm | 606 mm | 615 mm | 626 mm | 649 mm | 659 mm |
| Rake | 43 mm | 43 mm | 43 mm | 42 mm | 43 mm | 44 mm | 23 mm |
| Trail | 73 mm | 67 mm | 75 mm | 66 mm | 65 mm | 62 mm | 84 mm |
| Stack | 468 mm | 488 mm | 511 mm | 534 mm | 561 mm | 582 mm | 602 mm |
| Reach | 382 mm | 386 mm | 403 mm | 419 mm | 421 mm | 439 mm | 464 mm |
| Top Tube Length | 511 mm | 521 mm | 545 mm | 567 mm | 578 mm | 602 mm | 613 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 432 mm | 462 mm | 492 mm | 522 mm | 552 mm | 582 mm | 612 mm |
| Head Tube Angle | 70.25 ° | 71.25 ° | 71 ° | 72.5 ° | 72.5 ° | 72.75 ° | 72.75 ° |
| Head Tube Length | 70 mm | 88 mm | 78 mm | 97 mm | 125 mm | 146 mm | 167 mm |
| Chainstay Length | 413 mm | 413 mm | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 986 mm | 988 mm | 1018 mm | 1027 mm | 1038 mm | 1061 mm | 1071 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 751 mm | 776 mm | 803 mm | 832 mm | 858 mm | 886 mm | 910 mm |
| Wheels | 650 | 650 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 167 cm | 173 cm | 179 cm | 185 cm | 191 cm | 197 cm | cm |
Model Overview
Grail CF SL 8 is a Canyon Grail model. There are 90 bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Canyon Grail 6 2023 is the most economical model, with a starting price of 1699$. Canyon Grail CF SLX 9 eTap 2023 on the other hand costs 6999$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Canyon Grail CF SL 8 price was 2899$. In conclusion, this bike price is 17.75% more expensive than the price of the average Gravel bike.
Gravel bikes average weight
On a deeper look, we notice that the average weight of a Gravel bike is 8.13 kg (17.92 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Grail CF SL 8 weighs 8.96 kg (19.75 lbs) and is considerably heavier than the average. In short, the average Gravel bike weight is 10.21% lower than this one.
Overview of components
Fork material
Grail CF SL 8 has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When leaving the production line, the Grail CF SL 8 model has aluminum wheels. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Grail CF SL 8 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
