Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCR
-
Groupset Deore, Shimano -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 163cm
SM
161cm - 173cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Grand Canyon WMN AL, Material: Aluminium (AL)
Suspension Fork
SR Suntour XCR, Travel: 100 mm, Fork steer tube diameter: 1 1/8"
Drivetrain
Rear Derailleur
Shimano Deore, 12-speed, 1x12 drivetrain for simpler, intuitive shifting. Long-cage design is compatible with wide-range cassettes.
Shift Levers
Shimano Deore M6100 12s, Right shift lever. Shifts up to 3 gears at a time.
Cassette
Shimano Deore M6100 12speed, Cassette packed with trickle-down performance features. Hyperglide+ tech provides fast, smooth shifting. Beam spider construction cuts weights and boosts stiffness. Gear range: 10-51.
Crank
Shimano MT510, Number of chainrings: 1
Bottom Bracket
Shimano BSA BB52
Chain
Shimano CN-M6100 12s
Wheels
Rims
Iridium / Shimano TX505, Rotor Mount: Center Lock | Iridium / Shimano TX505 SH11, Rotor Mount: Center Lock
Tires
Schwalbe Rapid Rob 27.5" x 2.25 MTB Tyre, Casing: K-Guard | Schwalbe Tough Tom 2.25"
Brakes
Brakes
Shimano MT200
Disk Rotors
Shimano RT10, Disc Mount: Centerlock
Cockpit
Stem
Iridium, Clamping Diameter: 31,8 mm
Handlebar
Iridium Flatbar, Material: Aluminium, Rise: 5 mm
Grips
Iridium
Seat
Saddle
Iridium WMN Fitness
Seatpost
Iridium, Clamp diameter: 30,9 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.57 mm | 1.49 mm | 1.46 mm |
| Bottom Bracket Height | 301 mm | 301 mm | 301 mm | 315 mm |
| Front Center | 608 mm | 634 mm | 663 mm | 694 mm |
| Rake | 47 mm | 47 mm | 47 mm | 48 mm |
| Trail | 90 mm | 90 mm | 90 mm | 96 mm |
| Stack | 565 mm | 593 mm | 602 mm | 623 mm |
| Reach | 363 mm | 378 mm | 404 mm | 427 mm |
| Top Tube Length | 523 mm | 546 mm | 575 mm | 604 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 305 mm | 350 mm | 395 mm | 440 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 105 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm | 437 mm |
| Wheelbase | 1031 mm | 1057 mm | 1086 mm | 1124 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 54 mm | 59 mm |
| Standover Height | 677 mm | 707 mm | 747 mm | 797 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 27" | 27" | 27" | 29" |
| Rider Max Height | 153 cm | 163 cm | 173 cm | cm |
About this model
Grand Canyon 5 WMN belongs to the Canyon Grand Canyon model. Canyon released 49 bikes variations of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
The most economical model, the Canyon Grand Canyon 5 WMN 2022 has a starting price of 901$. Canyon Grand Canyon 9 2022 on the other hand is the most expensive at 1910$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2022 for 901$. Comparing this to the average Crosscountry bike price, we see that the price is 111.43% smaller.
Grand Canyon 5 WMN components
Fork
Canyon Grand Canyon 5 WMN 2022 bike is equipped with the Suntour XCR fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The wheels on Grand Canyon 5 WMN are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Canyon Grand Canyon 5 WMN is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
