Canyon Grizl 5 2023
2023 Road
Estimate price |
1,490$
Weight | 11.08 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Sora, FSA -
Suspension Rigid -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XXS
157cm - 167cm
XS
165cm - 173cm
SM
171cm - 179cm
MD
177cm - 185cm
LG
183cm - 190cm
XL
188cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Grizl AL, Aluminium frame with Gravel Pro geometry, a range of mounting points, and extended wheelbase for extra off-road stability., Axle dimension: 12x142 mm, Tyre Clearance: 50 mm, Material: Aluminium (AL), Weight: 1.82 kg
Suspension Fork
Canyon FK0087 CF Disc, Light, robust carbon frame with 3-screw mounting points on each side for attaching bottle cages and Anything Cages., Axle dimension: 12x100 mm, Fork steer tube diameter: 1 1/4", Material: Carbon (CF), Weight: 518 g
Drivetrain
Rear Derailleur
Shimano Sora R3000 GS
Front Derailleur
Shimano Sora R3000
Shift Levers
Shimano Sora R3000, Number of pistons: 2
Cassette
Shimano HG400 11-34 9s, Number of sprockets: 9 | Shimano Alivio CS-HG400 9-speed Cassette
Crank
FSA Omega Mega Exo 170mm Black, Number of chainrings: 2
Bottom Bracket
FSA BB86 Alloy Cups
Chain
KMC Connection Link 10s | KMC X10-93 10s | KMC X10-93 NP/GY 10-speed Chain 122 Links
Pedals
None included
Wheels
Rims
Rodi Cyclone DB, Axle dimension: 12x100 mm, Rotor mount: Center Lock, Rim height: 27 mm, Rim material: Aluminium | Rodi Cyclone DB SH11, Axle dimension: 12x142 mm, Rotor mount: Center Lock, Rim height: 27 mm, Rim material: Aluminium
Tires
Continental Terra Trail ProTection SL 40-584, Width: 45mm | Schwalbe G-One Allround Super Ground 27.5" & 28" Gravel Tyres | Schwalbe G-One R Super Race 28" x 45mm Gravel Tyre
Brakes
Brakes
Mechanical Disc
Brake Levers
Shimano Sora R3000, Number of pistons: 2
Cockpit
Stem
Canyon ST0035, A lightweight and durable aluminium stem for use on gravel and road bikes., Fork steer tube diameter: 1 1/4", Clamping diameter: 31,8 mm
Handlebar
Canyon HB0064 Ergo, Robust aluminium handlebar with flared drops for enhanced off-road control., Clamping diameter: 31,8 mm, Width: 440 mm
Seat
Saddle
Selle Italia Model X, Gender: Unisex, Weight: 315 g
Seatpost
Canyon SP0057 VCLS, With vibration-absorbing design for top rear-end comfort., Setback: 20 mm, Clamp diameter: 27,2 mm, Material: Carbon (CF), Weight: 265 g
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXXS | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.38 mm | 1.4 mm | 1.4 mm | 1.44 mm | 1.48 mm | 1.46 mm | 1.47 mm |
| Front Center | 594 mm | 596 mm | 599 mm | 620 mm | 621 mm | 631 mm | 650 | 665 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 44 mm | 43 mm | 43 mm | 43 mm |
| Trail | 81 mm | 76 mm | 71 mm | 80 mm | 70 mm | 68 mm | 65 mm | 65 mm |
| Stack | 514 mm | 524 mm | 539 mm | 558 mm | 581 mm | 607 mm | 628 mm | 646 mm |
| Reach | 374 mm | 379 mm | 384 mm | 399 mm | 404 mm | 411 mm | 429 mm | 438 mm |
| Top Tube Length | 526 mm | 534 mm | 543 mm | 564 mm | 576 mm | 590 mm | 614 mm | 629 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 402 mm | 432 mm | 462 mm | 492 mm | 522 mm | 552 mm | 582 mm | 612 mm |
| Head Tube Angle | 69 ° | 69.75 ° | 70.5 ° | 70.25 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 115 mm | 122 mm | 135 mm | 121 mm | 141 mm | 166 mm | 186 mm | 205 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1009 mm | 1011 mm | 1014 mm | 1046 mm | 1047 mm | 1057 mm | 1076 mm | 1091 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 711 mm | 732 mm | 754 mm | 782 mm | 809 mm | 837 mm | 862 mm | 886 mm |
| Wheels | 650 | 650 | 650 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 159 cm | 167 cm | 173 cm | 179 cm | 185 cm | 190 cm | 194 cm | cm |
About this model
Grizl 5 belongs to the Canyon Grizl model. Canyon released 80 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Canyon Grizl 5 2023 is the most affordable bike of this model and has a price of 1376$. On the other hand, Canyon Grizl CF SLX 8 Force AXS Trail 2023, is the most expensive and costs 5611$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 1376$. If we compare this with the average Gravel bike cost we notice that the price is 78.92% smaller.
Average weight for Gravel bikes
Gravel bikes have an average weight of 8.13 kg (17.92 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 11.08 kg (24.43 lbs), Canyon bike is much heavier than average. In conclusion, the average Gravel bike weighs 36.29% less than Grizl 5.
Grizl 5 components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the Grizl 5 bike is equipped with the aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
