Canyon Neuron 7 2023
2023 Mountain
Estimate price |
3,096$
Weight | 13.94 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Fork Fox Performance Float 34
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
158cm - 167cm
SM
165cm - 176cm
MD
174cm - 184cm
LG
182cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Neuron, Rugged full-suspension aluminium MTB frame with a perfectly balanced geometry for a confidence inspiring ride., Axle dimension: 12x148 mm, Material: Aluminium (AL)
Suspension Fork
FOX 34 Float Performance GRIP, Axle dimension: 15x110 mm, Stanchion Diameter: 34 mm, Travel: 140 mm, Fork steer tube diameter: 1 1/8" - 1,5", Offset: 44 mm
Rear Shock
FOX Float DPS Performance
Drivetrain
Rear Derailleur
Shimano DEORE XT M8100, Cage length: long, Weight: 286 g
Shift Levers
Shimano DEORE XT M8100
Cassette
Shimano DEORE XT M8100, Number of sprockets: 12 | Shimano XT CS-M8100 12-speed Cassette
Crank
Shimano DEORE XT M8120, Number of chainrings: 1
Bottom Bracket
Shimano BSA BB52, Bottom bracket standard: BSA HT2 68/73, Weight: 98 g
Chain
Shimano CN-M6100 | Shimano CN-M6100 Deore 12-speed Chain 138 Links | Shimano SM-CN910 12-speed Quick-Link Chain Connector
Pedals
None included
Wheels
Rims
DT Swiss M 1900, Axle dimension: 15x110 mm, Rotor mount: Center Lock, Rim height: 20 mm, Weight: 912 g | DT Swiss M1900, Axle dimension: 12x148 mm, Rotor mount: Center Lock, Rim height: 20 mm, Weight: 967 g
Tires
Schwalbe Nobby Nic 29x2.4" bronze skin, Width: 2.4" | Schwalbe Wicked Will 29x2.4" bronze skin, Width: 2.4"
Brakes
Brakes
Shimano SLX M7120
Cockpit
Stem
Iridium Stem, Fork steer tube diameter: 1 1/8"
Handlebar
Iridium Flatbar, Material: Aluminium, Rise: 5 mm
Grips
Ergon GA20
Seat
Saddle
Ergon SM10, Gender: Male, Weight: 10 g
Seatpost
Iridium Dropper, Clamp diameter: 30,9 mm, Material: Aluminium (AL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.38 mm | 1.37 mm | 1.33 mm | 1.28 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 336 mm | 336 mm | 336 mm |
| Front Center | 710 mm | 735 mm | 766 mm | 797 mm | 834 mm |
| Rake | 42 mm | 43 mm | 44 mm | 44 mm | 43 mm |
| Trail | 112 mm | 111 mm | 119 mm | 119 mm | 120 mm |
| Stack | 594 mm | 603 mm | 633 mm | 646 mm | 663 mm |
| Reach | 417 mm | 437 mm | 462 mm | 487 mm | 517 mm |
| Top Tube Length | 563 mm | 586 mm | 618 mm | 646 mm | 681 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 390 mm | 390 mm | 425 mm | 460 mm | 500 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 125 mm | 143 mm |
| Chainstay Length | 437 mm | 437 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1146 mm | 1171 mm | 1210 mm | 1241 mm | 1278 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 763 mm | 767 mm | 767 mm | 773 mm | 779 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 27" | 27" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 165 cm | 174 cm | 182 cm | 191 cm |
| Rider Max Height | 167 cm | 176 cm | 184 cm | 193 cm | cm |
About this model
Neuron 7 is a Canyon Neuron model. Canyon released 68 bikes variations of this model so far. You can easily view all of the Canyon Neuron bikes models from 2023, here.
Model range prices
Canyon Neuron 5 2023 is the cheapest bike model and costs 2099$. Canyon Neuron CF SLX LTD 2023 is the most expensive one and costs 6901$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Canyon Neuron 7 price was 2866$. Comparing this to the average Trail bike price, we see that the price is 3.77% more expensive.
Average weight for Trail bikes
Trail bikes have an average weight of 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
a bit heavier than average, Neuron 7 has a weight of 13.94 kg (30.73 lbs). In other words, this model is 7.4% heavier than the average Trail bike.
Overview of components
Fork
Canyon Neuron 7 2023 bike is equipped with the Fox Performance Float 34 fork, and has 140mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Canyon Neuron 7 2023, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Canyon Neuron 7 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Dropper post
Canyon Neuron 7 comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
