Canyon Neuron LTD 2023
2023 Mountain
Estimate price |
3,440$
Weight | 13.94 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 130mm -
Fork Fox Performance Float 34
-
Groupset GX Eagle Transmission, X01 Eagle AXS -
Suspension Full -
Battery SRAM Powerpack -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 176cm
MD
174cm - 184cm
LG
182cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Neuron AL, Axle dimension: 12x148 mm, Material: Aluminium (AL)
Suspension Fork
FOX 34 Float Performance GRIP, Axle dimension: 15x110 mm, Stanchion Diameter: 34 mm, Travel: 140 mm, Fork steer tube diameter: 1 1/8" - 1,5", Offset: 44 mm
Rear Shock
FOX Float DPS Performance
Drivetrain
Rear Derailleur
SRAM GX Eagle AXS Transmission
Shift Levers
SRAM AXS Pod Ultimate
Cassette
SRAM GX Eagle Transmission Cassette 12s 10-52, Number of sprockets: 12 | SRAM XS-1275 T-Type GX 12-speed Cassette 10-52
Crank
SRAM GX Eagle, Number of chainrings: 1
Bottom Bracket
SRAM BSA DUB, Bottom bracket standard: BSA 73, Weight: 87 g
Chain
SRAM GX Eagle Transmission | SRAM Eagle Transmission PowerLock | SRAM GX T-Type 12-speed Chain 126L
Pedals
None included
Wheels
Rims
DT Swiss M1900, Axle dimension: 15x110 mm, Rotor mount: IS 6-bolt | DT Swiss M1900, Axle dimension: 12x148 mm, Rotor mount: IS 6-bolt, Weight: 1.07 kg
Tires
Schwalbe Nobby Nic 29x2.4 black skin, Width: 2.4" | Schwalbe Wicked Will 29"x2.4", Width: 2.4" | Maxxis Minion DHR II EXO+ 3C MaxxTerra WT 29" x 2.4" MTB Tyre | Maxxis Minion DHR II EXO 3C MaxxGrip WT 29" x 2.4" MTB Tyre | Maxxis Minion DHR II DH 27.5" x 2.4" MaxxGrip MTB Tyre
Brakes
Brakes
SRAM Code RS
Cockpit
Stem
Canyon V12, Fork steer tube diameter: 1 1/8", Clamping diameter: 31,8 mm
Handlebar
Canyon H15 Riserbar, Material: Aluminium, Rise: 15 mm
Grips
Ergon GA20
Seat
Saddle
Ergon SM10, Gender: Male, Weight: 10 g
Seatpost
Canyon G5, Clamp diameter: 30,9 mm, Material: Aluminium (AL)
Motor & Battery
Battery
SRAM Powerpack
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.38 mm | 1.37 mm | 1.33 mm | 1.28 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 336 mm | 336 mm | 336 mm |
| Front Center | 710 mm | 735 mm | 764 mm | 795 mm | 832 mm |
| Rake | 42 mm | 43 mm | 42 mm | 42 mm | 42 mm |
| Trail | 112 mm | 111 mm | 121 mm | 121 mm | 121 mm |
| Stack | 594 mm | 603 mm | 633 mm | 646 mm | 663 mm |
| Reach | 417 mm | 437 mm | 462 mm | 487 mm | 517 mm |
| Top Tube Length | 563 mm | 583 mm | 615 mm | 642 mm | 673 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 390 mm | 390 mm | 425 mm | 460 mm | 500 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 125 mm | 143 mm |
| Chainstay Length | 437 mm | 437 mm | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1146 mm | 1171 mm | 1210 mm | 1241 mm | 1278 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 767 mm | 767 mm | 767 mm | 773 mm | 779 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm | 140 mm |
| Rear Travel | 130 mm | 130 mm | 130 mm | 130 mm | 130 mm |
| Wheels | 27" | 27" | 29" | 29" | 29" |
| Rider Max Height | 167 cm | 176 cm | 184 cm | 193 cm | cm |
Model Overview
Neuron LTD completes the Canyon Neuron model. 68 bikes variations carry this model name so far. You can easily view all of the Canyon Neuron bikes models from 2023, here.
Model range prices
Canyon Neuron 5 2023 is the most affordable bike of this model and has a price of 2099$. On the other hand, Canyon Neuron CF SLX LTD 2023, is the most expensive and costs 6901$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3184$. Comparing this to the average Trail bike price, we see that the price is 15.28% more expensive.
Trail bikes average weight
The average weight for Trail bikes is 12.98 kg (28.62 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Neuron LTD weighs 13.94 kg (30.73 lbs) and is a bit heavier than the average. To sum up, it’s 7.4% heavier than the average weight of Trail bikes.
Overview of components
Fork
Canyon Neuron LTD 2023 bike is equipped with the Fox Performance Float 34 fork, and has 140mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the FOX Float DPS Performance rear shock model, which has a travel of 130mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The wheels on Neuron LTD are the 27.5″ aluminum type. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Canyon Neuron LTD has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Dropper post
A dropper post is included with the Neuron LTD. Therefore, climbing or descending will be a breeze.
