Canyon Pathlite 5 2021
2021 Urban
Estimate price |
1,008$
Weight | 12.92 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b / 29" -
Travel Front 75mm -
Fork SunTour NRX D
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
167cm - 179cm
MD
177cm - 185cm
LG
183cm - 191cm
XL
189cm - 197cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Pathlite AL
Suspension Fork
SR Suntour NRX-D Coil, Travel: 75 mm, Technology: LO, Axle Dimension: 9 x 100 mm, Steerer: 1 1/8''
Drivetrain
Rear Derailleur
Shimano Deore M5100 11s
Shift Levers
Shimano Deore M5100
Cassette
Shimano Deore M5100 11s 11-51
Crank
FC-M5100-1, DEORE 32
Bottom Bracket
Shimano BSA BB52
Chain
KMC X11-93
Wheels
Rims
Alexrims DP23 | Shimano TX505 S11
Tires
Schwalbe G-One Bite 40 mm
Brakes
Brakes
Shimano MT200
Disk Rotors
Shimano RT10
Cockpit
Stem
Iridium
Handlebar
Iridium Flatbar, Material: Aluminium, Rise: 5 mm
Grips
Ergon GA3
Seat
Saddle
Canyon Sport Saddle EP1249
Seatpost
Iridium
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.52 mm | 1.54 mm | 1.54 mm | 1.57 mm | 1.57 mm |
| Front Center | 633 mm | 638 mm | 647 mm | 664 mm | 674 mm | 700 |
| Rake | 46 mm | 47 mm | 47 mm | 46 mm | 46 mm | 47 mm |
| Trail | 71 mm | 70 mm | 70 mm | 72 mm | 72 mm | 70 mm |
| Stack | 572 mm | 594 mm | 609 mm | 628 mm | 646 mm | 670 mm |
| Reach | 379 mm | 392 mm | 396 mm | 407 mm | 411 mm | 428 mm |
| Top Tube Length | 554 mm | 574 mm | 582 mm | 599 mm | 608 mm | 632 mm |
| Seat Tube Angle | 73.3 ° | 73.3 ° | 73.3 ° | 73.3 ° | 73.3 ° | 73.3 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm | 610 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 90 mm | 90 mm | 105 mm | 125 mm | 145 mm | 170 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1061 mm | 1063 mm | 1072 mm | 1089 mm | 1099 mm | 1125 mm |
| Bottom Bracket Drop | 44 mm | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm |
| Standover Height | 769 mm | 795 mm | 818 mm | 842 mm | 867 mm | 893 mm |
| Front Travel | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 650 | 29" | 29" | 29" | 29" | 29" |
| Rider Max Height | 169 cm | 179 cm | 185 cm | 191 cm | 197 cm | cm |
About this model
Pathlite 5 is part of the Canyon Pathlite model. There are 41 bikes that carry this model name. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Canyon Pathlite 5 2021 is the most affordable bike of this model and has a price of 933$. On the other hand, Canyon Pathlite 7 WMN 2021, is the most expensive and costs 1549$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Fitness bikes average price
Our math shows that the average cost of a dependable Fitness bike is 656$. However, even if your budget is less than the average, you might still be able to get a top-quality Fitness bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2021 for 933$. If we compare this with the average Fitness bike cost we notice that the price is 42.23% more expensive.
Average weight for Fitness bikes
If we make a quick analysis of the average weight of a Fitness bike, we get 11.24 kg (24.78 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Weighing 12.92 kg (28.48 lbs), the Pathlite 5 model is considerably heavier than average. To sum up, it’s 14.95% heavier than the average weight of Fitness bikes.
Overview of components
Fork
The SunTour NRX D is included from the factory. It has a travel distance of 75mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Canyon Pathlite 5 2021, has a aluminum model. After 700c wheels, 650b is the second most popular choice for road bikes. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
For your safety, it is important to have quality breaks on your bike. Canyon Pathlite 5 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
