Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b / 700c -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
167cm - 179cm
MD
176cm - 184cm
LG
182cm - 191cm
XL
188cm - 197cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Roadlite AL, Material: Aluminium, Axle Dimension: 10 x 135 mm, Brake Mount: Flat Mount
Suspension Fork
Canyon FK0049 CF Disc, Material: Carbon, Steerer: 1 1/8'', Axle Dimension: 9 x 100 mm, Brake Mount: Flat Mount
Drivetrain
Rear Derailleur
Shimano Sora R3000 GS
Front Derailleur
Shimano Sora R3000
Shift Levers
Shimano Sora R3000 9s
Cassette
Shimano HG200 11-32 9s
Crank
Shimano Sora R3000, 50/34
Bottom Bracket
Shimano Pressfit BB-RS500
Chain
KMC X9-93
Wheels
Rims
Iridium / Shimano TX505 SH11
Tires
Schwalbe G-One Speed 30 mm
Brakes
Brakes
Shimano MT200
Disk Rotors
Shimano RT10, Disc Mount: Centerlock
Cockpit
Stem
Iridium
Handlebar
Iridium Flatbar, Material: Aluminium
Grips
Iridium
Headset
Femin FP-H863
Seat
Saddle
Iridium Fitness
Seatpost
Iridium
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.32 mm | 1.31 mm | 1.35 mm | 1.4 mm | 1.43 mm | 1.44 mm |
| Front Center | 603 mm | 618 mm | 631 mm | 641 mm | 655 mm | 678 mm |
| Rake | 46 mm | 46 mm | 54 mm | 54 mm | 46 mm | 55 mm |
| Trail | 58 mm | 64 mm | 50 mm | 50 mm | 64 mm | 49 mm |
| Stack | 518 mm | 531 mm | 554 mm | 578 mm | 602 mm | 626 mm |
| Reach | 393 mm | 406 mm | 411 mm | 414 mm | 420 mm | 436 mm |
| Top Tube Length | 549 mm | 566 mm | 578 mm | 588 mm | 601 mm | 624 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 442 mm | 482 mm | 522 mm | 552 mm | 582 mm | 612 mm |
| Head Tube Angle | 72.2 ° | 72.2 ° | 73 ° | 73 ° | 72.2 ° | 73 ° |
| Head Tube Length | 105 mm | 105 mm | 130 mm | 155 mm | 180 mm | 205 mm |
| Chainstay Length | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 1002 mm | 1013 mm | 1026 mm | 1036 mm | 1050 mm | 1074 mm |
| Bottom Bracket Drop | 60 mm | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm |
| Wheels | 650 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 169 cm | 179 cm | 184 cm | 191 cm | 197 cm | cm |
Model Overview
Roadlite 6.0 completes the Canyon Roadlite model. Canyon released 58 bikes variations of this model so far. Take a sneak peek at all Canyon Roadlite bikes models from 2019, by clicking here.
Model range prices
Canyon Roadlite WMN 6.0 2019 is the most economical model, with a starting price of 689$. Canyon Roadlite CF 9.0 LTD 2019 on the other hand costs 2999$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Fitness bikes
If you want an acceptable Fitness bike you should know that the average price is 656$. However, even though the average price of a Fitness bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Canyon released this model in 2019, its price was 689$. Comparing this to the average Fitness bike price, we see that the price is 5.03% higher.
Roadlite 6.0 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When it comes to wheels, the Roadlite 6.0 bike is equipped with the aluminum model. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Roadlite 6.0 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
