Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b / 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XXS
145cm - 159cm
XS
157cm - 168cm
SM
165cm - 176cm
MD
174cm - 183cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Roadlite WMN AL
Suspension Fork
Canyon FK049 - One One Eight CF Disc
Drivetrain
Rear Derailleur
Shimano 105, 11s, RD-R7000-GS
Front Derailleur
Shimano 105, 11s, FD-R7000
Shift Levers
Shimano SL-RS700, 11s, Ergonomic lever design for imporved hand grip, Simple, versatile and practical
Cassette
Shimano 105, 11s 11-34
Crank
Shimano 105, 11s
Bottom Bracket
Shimano RS500-PB
Chain
Shimano CN-HG601, 11s
Pedals
VP Components VP-536
Wheels
Front Hub
Shimano HB-TX505 | Shimano FH-TX505
Rear Hub
Shimano HB-TX505 | Shimano FH-TX505
Rims
Alex ATD560, XS frame uses 650b wheels
Tires
Schwalbe G-ONE SPEED
Brakes
Brakes
Shimano BR MT201 Flatmount
Cockpit
Stem
Canyon V15, Angle: +/- 6°, 1 1/8" Stem clamp, In-house developed Canyon stem with new clamping concept for added security, Square profile design for extra torsional stiffness, Compliant with Canyon Category 2 testing standards
Handlebar
Canyon H40
Grips
Ergon GS 2
Headset
Acros Az-44
Seat
Saddle
Iridium WMN Fitness
Seatpost
Iridium S34
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.43 mm | 1.44 mm | 1.47 mm |
| Stack | 522 mm | 538 mm | 566 mm | 593 mm |
| Reach | 351 mm | 375 mm | 394 mm | 404 mm |
| Top Tube Length | 502 mm | 530 mm | 557 mm | 575 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 345 mm | 385 mm | 420 mm | 460 mm |
| Head Tube Angle | 70 ° | 71.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 113 mm | 124 mm | 134 mm | 164 mm |
| Chainstay Length | 411 mm | 421 mm | 416 mm | 416 mm |
| Wheelbase | 980 mm | 1006 mm | 1012 mm | 1031 mm |
| Wheels | 650 | 650 | 700 | 700 |
| Rider Min Height | 145 cm | 157 cm | 165 cm | 174 cm |
| Rider Max Height | 159 cm | 168 cm | 176 cm | 183 cm |
About this model
Roadlite AL 7.0 WMN belongs to the Canyon Roadlite model. There are 58 bikes that carry this model name. You can easily view all of the Canyon Roadlite bikes models from 2019, here.
Model range prices
Canyon Roadlite WMN 6.0 2019 is the most affordable bike of this model and has a price of 689$. On the other hand, Canyon Roadlite CF 9.0 LTD 2019, is the most expensive and costs 2999$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Fitness bikes
If you want to purchase a solid Fitness bike, it is important to know that the average cost is 656$. However, even though the average price of a Fitness bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 999$. Doing a quick comparison, we notice that Roadlite AL 7.0 WMN price is 52.29% higher than the average cost of a Fitness bike.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The Roadlite AL 7.0 WMN 2019 bike is equipped with aluminum wheels when leaving the factory. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Roadlite AL 7.0 WMN comes in 4 sizes, that range from 145 cm – 183 cm (4.76 ft – 6 ft). In short, you can easily find one that suits you.
