Canyon Sender CFR Mullet TLD 2023
2023 Mountain
Estimate price |
6,999$
Weight | 16.26 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 200mm -
Travel Rear 200mm -
Fork RockShox BoXXer Ultimate
-
Groupset X01, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
172cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Sender CFR, Premium, world-class Canyon Factory Racing carbon frame. Meets our toughest category 5 testing standards. A Regular Downhill World Cup podium finisher. With independently adjustable reach and chainstay length. Mullet wheel sizing: 29" front, 27.5" rear., Material: Carbon (CF)
Suspension Fork
RockShox Boxxer Ultimate RC2, Axle dimension: 20x110 mm, Stanchion Diameter: 35 mm, Travel: 200 mm, Fork steer tube diameter: 1 1/8" - 1,5", Offset: 56 mm
Rear Shock
RockShox Super Deluxe Ultimate, Spring: 400
Drivetrain
Rear Derailleur
SRAM X01 DH, Cage length: medium
Shift Levers
SRAM X01 DH
Cassette
SRAM XG-795 DH 10-24 7s, Number of sprockets: 7
Crank
SRAM DESCENDANT DH TROY LEE DESIGN, Number of chainrings: 1
Bottom Bracket
SRAM BSA DUB, Bottom bracket standard: BSA 83
Chain
SRAM Connection Link 11s | SRAM PC 1110 11-speed
Chain Guide
e*thirteen LG1 Plus
Pedals
None included
Wheels
Rims
DT Swiss FR 560 240 EXP, Axle dimension: 20x110 mm, Rotor mount: IS 6-bolt, Wheelsize: 29" | DT Swiss FR 560 240 EXP, Rotor mount: IS 6-bolt, Wheelsize: 27.5"
Tires
Maxxis Minion DHR II 2.4", Width: 2.4" | Maxxis Minion DHR II 2.4" Wide Trail, Width: 2.4"
Brakes
Brakes
SRAM Code RSC
Cockpit
Stem
Canyon G5, G5 aluminium stem for double-crown forks. Developed with Canyon downhill pros, proven on the world’s toughest stages. Length: 45 mm. Clamping diameter: 31.8 mm., Fork steer tube diameter: 1 1/8"
Handlebar
Canyon G5, G5 parts are built for all-out downhill action. Super-robust aluminium handlebar, tested to category 5 standards and race-proven., Material: Aluminium, Rise: 20 mm
Grips
Canyon G5
Headset
Acros AZX-227
Seat
Saddle
Fizik Gravita Alpaca X5
Seatpost
Canyon G5, Canyon G5 aluminium seatpost. Length: 300 mm., Clamp diameter: 30,9 mm, Material: Aluminium (AL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.421 mm | 1.354 mm | 1.303 mm |
| Front Center | 803 mm | 830 mm | 860 mm |
| Rake | 56 mm | 56 mm | 56 mm |
| Trail | 128 mm | 128 mm | 128 mm |
| Stack | 618 mm | 623 mm | 632 mm |
| Reach | 435 mm | 460 mm | 485 mm |
| Top Tube Length | 561 mm | 587 mm | 619 mm |
| Seat Tube Angle | 65 ° | 65.7 ° | 66.4 ° |
| Seat Tube Length | 400 mm | 400 mm | 420 mm |
| Head Tube Angle | 63 ° | 63 ° | 63 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1237 mm | 1264 mm | 1294 mm |
| Bottom Bracket Drop | 21 mm | 21 mm | 21 mm |
| Standover Height | 741 mm | 745 mm | 749 mm |
| Front Travel | 200 mm | 200 mm | 200 mm |
| Rear Travel | 200 mm | 200 mm | 200 mm |
| Wheels | 29" | 29" | 29" |
| Rider Max Height | 177 cm | 185 cm | cm |
Model Overview
Sender CFR Mullet TLD is a Canyon Sender model. Canyon launched 33 bikes of this model so far. You can easily view all of the Canyon Sender bikes models from 2023, here.
Model range prices
Canyon Sender CFR 29 Underdog 2023 is the most affordable bike of this model and has a price of 5299$. On the other hand, Canyon Sender CFR Mullet TLD 2023, is the most expensive and costs 6999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Downhill bikes
If you want an acceptable Downhill bike you should know that the average price is 3391$. However, this doesn’t mean that if you spend less money on a Downhill bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2023 and its price was 6999$. Comparing this to the average Downhill bike price, we see that the price is 106.4% more expensive.
Average weight for Downhill bikes
On a deeper look, we notice that the average weight of a Downhill bike is 15.89 kg (35.03 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Canyon Sender CFR Mullet TLD it’s weighing 16.26 kg (35.85 lbs). At this weight, is slightly heavier than average. In short, the average Downhill bike weight is 2.33% lower than this one.
Sender CFR Mullet TLD components
Fork
The RockShox BoXXer Ultimate is included from the factory. It has a travel distance of 200mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
As for the rear shock, this bike has the RockShox Super Deluxe Ultimate model, with a travel of 200mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
As for the wheels, Canyon Sender CFR Mullet TLD 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The Sender CFR Mullet TLD has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
