Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Fork RockShox ZEB Ultimate
-
Groupset XT -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTube 750Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
No Pogo R intube II, Material: Aluminium, 29", Steuerrohr: 1.8" tapered, Ausfallende: 12x148 mm, Bremsaufnahme: Postmount 203 mm, UDH Schaltauge, Rahmenkennung: TBP051A
Suspension Fork
Rock Shox ZEB Ultimate, Federweg: 160 mm, 1.8" tapered, Rake: 44 mm
Drivetrain
Rear Derailleur
Shimano Deore XT, RD-M8130-11, 1x11, Linkglide
Shift Levers
Shimano Deore XT, SL-M8130-IR11, I-Spec EV, Linkglide
Cassette
Shimano Deore XT, CS-LG600-11, 11-50T, Linkglide
Crank
CENTURION R Pro II Gen4, mattschwarz/Alu gebürstet, Länge: 165 mm, CK-790
Chain
Shimano CN-LG500, Linkglide, Kettenlänge: 120 Links
Chain Guide
CENTURION Trail R, passend für Bosch Performance Line CX Gen4
Pedals
VP-527
Wheels
Front Hub
DT Swiss 370 Hybrid, 15x110 mm, 32H, Torque cap, 12x148 mm, 32H
Rear Hub
DT Swiss 370 Hybrid, 15x110 mm, 32H, Torque cap, 12x148 mm, 32H
Rims
PROCRAFT Altitude MD30, IW 30 mm, tubeless ready
Spokes
PROCRAFT stainless 2.0
Tires
Maxxis Assegai, 29x2.5" WT / Maxxis Assegai, 29x2.6", tubeless ready, 120TPI, 3C Maxxgrip, EXO+, tubeless ready, 120TPI, 3C Maxxterra, EXO+
Brakes
Brakes
Shimano Deore XT 4-Kolben, BR-M8120, resin pad, w/ fin
Brake Levers
Shimano Deore XT, BL-M8100
Cockpit
Stem
PROCRAFT Trail Expert 35 AICR, Winkel: 0°, Länge: 50 mm
Handlebar
PROCRAFT Trail Pro 35 ICR, Durchmesser: 35 mm, Breite: 780 mm, Rise: 20 mm
Seat
Saddle
PROCRAFT E-Pro
Seatpost
PROCRAFT DROP Pro, Durchmesser: 30.9 mm, Hub: 125 mm (S), 150 mm (M), 170 mm (L, XL), Remote: Shimano SL-MT500-IL, I-Spec EV
Motor & Battery
Motor
Bosch Performance Line CX, max. 85 Nm, 250 W
Battery
Bosch PowerTube 750Wh
Charger
Bosch Standard Charger, 4 Ampere
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.472 mm | 1.391 mm | 1.338 mm | 1.289 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm | 344 mm |
| Front Center | 762 mm | 787 mm | 816 mm | 845 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 125 mm | 125 mm | 125 mm | 125 mm |
| Stack | 633 mm | 633 mm | 642 mm | 651 mm |
| Reach | 430 mm | 455 mm | 480 mm | 505 mm |
| Top Tube Length | 582 mm | 607 mm | 634 mm | 661 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 400 mm | 420 mm | 460 mm | 500 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1220 mm | 1245 mm | 1274 mm | 1303 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
No Pogo R3700i is a Centurion E No model. Centurion released 25 e-bikes variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Enduro e-bikes
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, this doesn’t mean that if you spend less money on an Enduro e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
No Pogo R3700i components
Fork
Centurion No Pogo R3700i 2022 e-bike is equipped with the RockShox ZEB Ultimate fork, and has 160mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The No Pogo R3700i 2022 e-bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The No Pogo R3700i comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
No Pogo R3700i comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the No Pogo R3700i. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
