Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Fork Suntour AION
-
Groupset SX Eagle -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTube 625 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
No Pogo R intube, Material: Aluminium, 27.5", Steuerrohr: 1.5" straight, Ausfallende: 12x148 mm, Bremsaufnahme: Postmount 180 mm, Rahmenkennung: UBP042A
Suspension Fork
SR Suntour AION35 EVO BOOST LOR-PCS, Federweg: 160 mm, 1.5" tapered, Rake: 44 mm
Drivetrain
Rear Derailleur
SRAM SX Eagle, 1x12
Shift Levers
SRAM SX Eagle single click
Cassette
SRAM SX Eagle, CS PG-1210 Eagle, 11-50T
Crank
CENTURION R Pro II Gen4, mattschwarz/Alu gebürstet, Länge: 165 mm, CK-790
Chain
SRAM SX Eagle, CN SX Eagle-12, Kettenlänge: 116 Links
Chain Guide
CENTURION Trail R, passend für Bosch Performance Line CX Gen4
Pedals
VP-527
Wheels
Front Hub
Shimano HB-MT400-B / Shimano FH-MT400-B, 15x110 mm, 32H, 12x148 mm, 32H
Rear Hub
Shimano HB-MT400-B / Shimano FH-MT400-B, 15x110 mm, 32H, 12x148 mm, 32H
Rims
PROCRAFT Altitude MD30, IW 30 mm, tubeless ready
Spokes
PROCRAFT stainless 2.0
Tires
Maxxis Minion DHF, 27.5x2.6" / Maxxis Minion DHR II, 27.5x2.6, tubeless ready, 60TPI, EXO
Brakes
Brakes
Tektro HD-M745, organic pad
Brake Levers
Tektro HD-M745-1
Cockpit
Stem
PROCRAFT Trail Expert 35, Winkel: 0°, Länge: 50 mm
Handlebar
PROCRAFT Trail Pro 35, Durchmesser: 35 mm, Breite: 780 mm, Rise: 20 mm
Seat
Saddle
PROCRAFT Race
Seatpost
PROCRAFT DROP Pro, Durchmesser: 30.9 mm, Hub: 100 mm (S), 150 mm (M), 170 mm (L), 200 mm (XL), Remote: PROCRAFT I-Spec II
Motor & Battery
Motor
Bosch Performance Line CX, max. 85 Nm, 250 W
Battery
Bosch PowerTube 625 Wh
Charger
Bosch Standard Charger, 4 Ampere
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 4.201 mm | 4.454 mm | 4.71 mm | 4.962 mm |
| Stack | 605 mm | 628 mm | 650 | 650 |
| Top Tube Length | 576 mm | 607 mm | 638 mm | 663 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 400 mm | 450 mm | 500 mm | 500 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 110 mm | 135 mm | 160 mm | 160 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1174 mm | 1209 mm | 1245 mm | 1270 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
No Pogo R860i is part of the Centurion E No model. 25 e-bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro e-bikes
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, you could also get a good Enduro e-bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
No Pogo R860i components
Fork
The fork installed on this bike is the Suntour AION model. The travel on this model is 160mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the No Pogo R860i model has 27.5″ aluminum wheels. These wheels will provide you with more control over the e-bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Centurion No Pogo R860i has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Centurion No Pogo R860i includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
