centurion Overdrive Gravel Z4000 2022
2022 E-bike
Weight | 15.3 kg
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Ultegra, FSA -
Suspension Rigid -
Motor Fazua 250W 60Nm mid-drive -
Battery FAZUA evation 2.0 battery 250Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Overdrive Z, Material: Aluminium, 28", Steuerrohr: 1.5" straight, Ausfallende: 12x142 mm, Bremsaufname: Flatmount 160 mm, Rahmenkennung: ABP065B
Suspension Fork
CENTURION CARBON road/gravel, 1.5" tapered
Drivetrain
Rear Derailleur
Shimano Ultegra, RD-R8000-GS, 2x11
Shift Levers
Shimano Ultegra, ST-R8020-L, ST-R8020-R
Cassette
Shimano 105, CS-R7000, 11-32T
Crank
FSA CK-746-1/IS, Länge: 170 mm (XS/S), 175 mm (M, L/ XL), w/ Lockring ML097
Bottom Bracket
FAZUA evation 2.0 bottom bracket
Chain
Shimano CN-HG701-11
Pedals
VP-993
Wheels
Front Hub
DT Swiss 350 Road db CL, 12x100 mm, 28H, 12x142 mm, 28H
Rear Hub
DT Swiss 350 Road db CL, 12x100 mm, 28H, 12x142 mm, 28H
Rims
PROCRAFT Altitude GD30, IW 21 mm, tubless ready
Spokes
PROCRAFT stainless 2.0
Tires
Maxxis Rambler, 40-622, tubeless ready, EXO, TR
Brakes
Brakes
Shimano Ultegra, BR-R8070, resin pad, w/ fin
Cockpit
Stem
PROCRAFT Comp, Winkel: 7°, Länge: 60 mm (XS/ S), 70 mm (M), 80 mm (L/ XL)
Handlebar
PROCRAFT Gravel Pro, Durchmesser: 31.8 mm, Breite: 420 mm (XS/ S), 440 mm (M, L/ XL)
Seat
Saddle
PROCRAFT Race III
Seatpost
PROCRAFT Pro Off. Light, Durchmesser: 30.9 mm, Länge: 350 mm
Motor & Battery
Motor
FAZUA evation 2.0 drive pack, max. 60Nm, 250W
Battery
FAZUA evation 2.0 battery 250Wh
Charger
FAZUA evation 2.0 charger, 2 Ampere
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | MD | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.49 mm | 1.5 mm |
| Bottom Bracket Height | 277 mm | 277 mm | 277 mm |
| Front Center | 605 mm | 620 mm | 635 mm |
| Rake | 51 mm | 50 mm | 50 mm |
| Trail | 69 mm | 66 mm | 61 mm |
| Stack | 548 mm | 575 mm | 601 mm |
| Reach | 372 mm | 386 mm | 400 mm |
| Top Tube Length | 531 mm | 552 mm | 574 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 480 mm | 530 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 71.25 ° | 72 ° |
| Head Tube Length | 125 mm | 150 mm | 175 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1020 mm | 1035 mm | 1050 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 |
About this model
Overdrive Gravel Z4000 is a Centurion E Overdrive model. Centurion launched 16 e-bikes of this model so far. Take a sneak peek at all Centurion E Overdrive e-bikes models from 2022, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel e-bikes average price
According to our math, the average price for a trustworthy Gravel e-bike is 3642$. However, even though the average price of a Gravel e-bike is lower, you might still be able to get a top-quality e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Average weight for Gravel e-bikes
On a deeper look, we notice that the average weight of a Gravel e-bike is 13.58 kg (29.94 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Overdrive Gravel Z4000 weighs 15.3 kg (33.73 lbs) and is considerably heavier than the average. To sum up, it’s 12.67% heavier than the average weight of Gravel e-bikes.
Overview of components
Fork material
When it comes to the fork, this e-bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The Overdrive Gravel Z4000 2022 e-bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Centurion Overdrive Gravel Z4000 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
