Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Ultegra, FSA -
Suspension Rigid -
Motor Fazua 250W 60Nm mid-drive -
Battery FAZUA evation 2.0 battery 250Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Overdrive Z, Material: Aluminium, 28", Steuerrohr: 1.5" straight, Ausfallende: 12x142 mm, Bremsaufname: Flatmount 160 mm, Rahmenkennung: ABP065B
Suspension Fork
CENTURION CARBON road/gravel, 1.5" tapered
Drivetrain
Rear Derailleur
Shimano Ultegra, RD-R8000-GS, 2x11
Shift Levers
Shimano Ultegra, ST-R8020-L, ST-R8020-R
Cassette
Shimano 105, CS-R7000, 11-32T
Crank
FSA CK-746-1/IS, Länge: 170 mm (XS/S), 175 mm (M, L/ XL), w/ Lockring ML097
Bottom Bracket
FAZUA evation 2.0 bottom bracket
Chain
Shimano CN-HG701-11
Pedals
VP-993
Wheels
Front Hub
DT Swiss 350 Road db CL, 12x100 mm, 28H, 12x142 mm, 28H
Rear Hub
DT Swiss 350 Road db CL, 12x100 mm, 28H, 12x142 mm, 28H
Rims
PROCRAFT Altitude GD30, IW 21 mm, tubless ready
Spokes
PROCRAFT stainless 2.0
Tires
Maxxis Rambler. 40-622, tubeless ready, EXO, TR
Brakes
Brakes
Shimano Ultegra, BR-R8070, resin pad, w/ fin
Cockpit
Stem
PROCRAFT Comp, Winkel: 7°, Länge: 60 mm (XS/ S), 70 mm (M), 80 mm (L/ XL)
Handlebar
PROCRAFT Gravel Pro, Durchmesser: 31.8 mm, Breite: 420 mm (XS/ S), 440 mm (M, L/ XL)
Seat
Saddle
PROCRAFT Race III
Seatpost
PROCRAFT Pro Off. Light, Durchmesser: 30.9 mm, Länge: 350 mm
Motor & Battery
Motor
FAZUA evation 2.0 drive pack, max. 60Nm, 250W
Battery
FAZUA evation 2.0 battery 250Wh
Charger
FAZUA evation 2.0 charger, 2 Ampere
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | MD | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.49 mm | 1.5 mm |
| Bottom Bracket Height | 277 mm | 277 mm | 277 mm |
| Front Center | 605 mm | 620 mm | 635 mm |
| Rake | 51 mm | 50 mm | 50 mm |
| Trail | 69 mm | 66 mm | 61 mm |
| Stack | 548 mm | 575 mm | 601 mm |
| Reach | 372 mm | 386 mm | 400 mm |
| Top Tube Length | 531 mm | 552 mm | 574 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 480 mm | 530 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 71.25 ° | 72 ° |
| Head Tube Length | 125 mm | 150 mm | 175 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1020 mm | 1035 mm | 1050 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 |
Model Overview
Overdrive Gravel Z4000 belongs to the Centurion E Overdrive model. There are 16 e-bikes that carry this model name. Take a sneak peek at all Centurion E Overdrive e-bikes models from 2023, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel e-bikes
If you want an acceptable Gravel e-bike you should know that the average price is 3642$. However, even though the average price of a Gravel e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
Overdrive Gravel Z4000 has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the Overdrive Gravel Z4000 e-bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Overdrive Gravel Z4000 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
