Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Speeddrive, Material: Aluminium, 28", Steuerrohr: 1 1/8"-1.5", Ausfallende: 12x142 mm, Bremsaufnahme: Flatmount 160 mm, Rahmenkennung: S76570RCAA02XXF
Suspension Fork
CENTURION ALLOY TA road/gravel, 1.5" tapered
Drivetrain
Rear Derailleur
Shimano Tiagra, RD-4700-GS, 2x10
Shift Levers
Shimano Tiagra, SL-4700-L, SL-4700-R
Cassette
Shimano CS-HG500-10, 11-34T
Crank
Shimano Tiagra 50-34T, FC-4700, Länge: XXS, XS: 170 mm, S-M, M-L, XL, XXL: 175 mm
Bottom Bracket
Shimano Pressfit BB-RS500-PB, 86.5 mm
Chain
KMC X10 BK/BK
Pedals
VP-899
Wheels
Front Hub
Shimano DH-UR705-3D / Shimano FH-RS470, hub dynamo, 6V, 3W, 12x100 mm, 32H, 12x142 mm, 32H
Rear Hub
Shimano DH-UR705-3D / Shimano FH-RS470, hub dynamo, 6V, 3W, 12x100 mm, 32H, 12x142 mm, 32H
Rims
PROCRAFT Altitude MPD19, IW 20 mm
Spokes
PROCRAFT stainless 2.0
Tires
WTB Byway, 40-622 tanwall
Brakes
Brakes
Tektro HD-R290, organic pads
Brake Levers
Tektro HD-R290
Cockpit
Stem
PROCRAFT Comp II, Winkel: 7°, Länge: 80 mm (XXS), 90 mm (XS), 100 mm (S/M), 110 mm (M/L), 120 mm (XL, XXL)
Handlebar
PROCRAFT Flat Pro, Durchmesser: 31.8 mm, Breite: 660 mm
Seat
Saddle
PROCRAFT Retro II
Seatpost
PROCRAFT Pro III, Durchmesser: 27.2 mm, Länge: 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM/MD | MD/LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.49 mm | 1.51 mm | 1.53 mm | 1.55 mm | 1.57 mm |
| Front Center | 604 mm | 616 mm | 629 mm | 641 mm | 653 mm | 665 mm |
| Rake | 51 mm | 50 mm | 51 mm | 50 mm | 50 mm | 50 mm |
| Trail | 73 mm | 72 mm | 69 mm | 69 mm | 67 mm | 66 mm |
| Stack | 551 mm | 571 mm | 591 mm | 611 mm | 631 mm | 651 mm |
| Reach | 375 mm | 383 mm | 391 mm | 399 mm | 407 mm | 415 mm |
| Top Tube Length | 533 mm | 546 mm | 560 mm | 574 mm | 587 mm | 601 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 560 mm | 590 mm | 620 mm |
| Head Tube Angle | 70 ° | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° | 71.25 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 180 mm | 200 mm | 220 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1025 mm | 1037 mm | 1050 mm | 1062 mm | 1074 mm | 1086 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Speeddrive 500 EQ is a Centurion Speeddrive model. Centurion released 4 bikes variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Commuter bikes average price
According to our calculations, the average cost of a Commuter bike that is reliable is 762$. However, you could also get a good Commuter bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Commuter bikes average weight
On a deeper look, we notice that the average weight of a Commuter bike is 14.29 kg (31.5 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 12.6 kg (27.78 lbs), Centurion bike is considerably lighter than average. In short, the average Commuter bike weight is 13.41% higher than this one.
Overview of components
Fork material
The fork on this bike is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
The wheels on Speeddrive 500 EQ are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Centurion Speeddrive 500 EQ has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
