Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Cervélo All-Carbon, Tapered Caledonia Fork
Drivetrain
Rear Derailleur
Shimano 105, R7000 GS, 11 speed
Front Derailleur
Shimano 105, R7000, 11 speed
Shift Levers
Shimano 105, R7020, 11 speed
Cassette
Shimano HG700, 11-34, 11 Speed
Crank
Shimano R7000/FC-RS510, 52/36T, 11 Speed
Bottom Bracket
FSA, BBright thread together, 24mm spindle OR JY-bb-24 bottom bracket
Chain
Shimano HG601, 11 speed
Wheels
Rims
Alexrims Boondocks 5, 12x142mm, 24H, 21mm IW, HG freehub, 6 bolt, tubeless compatible, Alexrims Boondocks 5, 12x100mm, 24H, 21mm IW, 6 bolt, tubeless compatible
Tires
Zaffiro Pro V G2.0 700x30c
Brakes
Brakes
Shimano 105
Cockpit
Stem
Cervélo ST27 Alloy
Handlebar
Cervélo Alloy, 31.8mm clamp
Headset
FSA IS2 1-1/8 x 1-1/2
Seat
Saddle
Cervélo Road Saddle
Seatpost
Cervélo Alloy 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.44 mm | 1.47 mm | 1.51 mm | 1.53 mm | 1.56 mm |
| Bottom Bracket Height | 259 mm | 259 mm | 262 mm | 262 mm | 264 mm | 264 mm |
| Front Center | 579.4 mm | 581.7 mm | 591.5 mm | 608.5 mm | 626 mm | 643 mm |
| Rake | 59 mm | 53 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Stack | 500 mm | 525 mm | 550 mm | 575 mm | 600 mm | 625 mm |
| Reach | 355 mm | 364 mm | 373 mm | 382 mm | 391 mm | 400 mm |
| Top Tube Length | 497 mm | 517 mm | 538 mm | 560 mm | 576 mm | 593 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 510 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 89.5 mm | 109.9 mm | 136 mm | 162.3 mm | 191.2 mm | 217.5 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 977 mm | 979 mm | 990 mm | 1007 mm | 1025 mm | 1042 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 74 mm | 74 mm | 71 mm | 71 mm |
| Standover Height | 696 mm | 736 mm | 768 mm | 791 mm | 818 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Caledonia 105 belongs to the Cervelo Caledonia model. 14 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Cervélo Caledonia 105 2023 is the most affordable bike of this model and has a price of 3200$. On the other hand, Cervélo Caledonia Ultegra Di2 2023, is the most expensive and costs 5500$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Endurance bikes
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Cervélo Caledonia 105 price was 3200$. Comparing the average cost of an Endurance bike to this one, you will see that Caledonia 105 price is 36.4% higher.
Overview of components
Fork material
Caledonia 105 has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The Caledonia 105 2023 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Caledonia 105 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
