Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 700c -
Suspension Rigid -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Cervélo All-Carbon, P5 Fork
Brakes
Brakes
Magura RT8 Hydraulic Rim
Cockpit
Headset
FSA IS2 Stainless Steel 1-1/8 x 1-1/8”
Seat
Seatpost
Cervélo Carbon, Aero, Rail-Adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.273 mm | 1.275 mm | 1.27 mm | 1.271 mm | 1.279 mm | 1.318 mm |
| Bottom Bracket Height | 256 mm | 261 mm | 261 mm | 261 mm | 261 mm | 261 mm |
| Front Center | 583 mm | 583 mm | 602 mm | 622 mm | 640 mm | 658 mm |
| Rake | 53 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 59 mm | 61 mm | 61 mm | 61 mm | 61 mm | 60 mm |
| Stack | 485 mm | 506 mm | 522 mm | 540 mm | 559 mm | 588 mm |
| Reach | 381 mm | 397 mm | 411 mm | 425 mm | 437 mm | 446 mm |
| Top Tube Length | 484 mm | 505 mm | 522 mm | 540 mm | 556 mm | 571 mm |
| Head Tube Angle | 71 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 84 mm | 97 mm | 114 mm | 133 mm | 153 mm | 183 mm |
| Chainstay Length | 399 mm | 399 mm | 399 mm | 399 mm | 399 mm | 399 mm |
| Wheelbase | 968 mm | 970 mm | 989 mm | 1009 mm | 1027 mm | 1046 mm |
| Bottom Bracket Drop | 80 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 742 mm | 768 mm | 784 mm | 802 mm | 821 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
P5 Frameset is part of the Cervelo P5 model. There are 27 frames that carry this model name. Take a sneak peek at all Cervelo P5 frames models from 2018, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Triathlon frames
If you want to purchase a solid Triathlon frame, it is important to know that the average cost is 3089$. However, you could also get a good Triathlon frame even if you pay a lower amount than the average price. In conclusion, always check frame reviews and their components before making a purchase to make sure you don’t overpay.
When Cervélo released this model in 2018, its price was 5000$. Comparing this to the average Triathlon frame price, we see that the price is 61.86% more expensive.
Overview of components
Fork material
P5 Frameset has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The P5 Frameset comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
