Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset RED AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Cervélo All-Carbon, Tapered R5CX Fork
Drivetrain
Rear Derailleur
SRAM Red AXS, 12 speed
Shift Levers
SRAM Red AXS, 12 speed
Cassette
SRAM Red, 10-33, 12 Speed
Crank
SRAM Red 1 AXS, 40T, DUB, with power meter
Bottom Bracket
SRAM DUB Ceramic, T47 BBright
Chain
SRAM Red, 12 speed
Wheels
Rims
Rear: Reserve 44, 25mm IW, Zipp ZR1 SS,12x142mm, XDR freehub, 24H, centerlock, tubeless compatible Front: Reserve 40, 25.5mm IW, Zipp ZR1 SS, 24H, centerlock, tubeless compatible
Tires
Panaracer CGCX TLC 700x33c
Brakes
Brakes
SRAM Red
Cockpit
Stem
Cervélo ST31 Carbon
Handlebar
Cervélo HB13 Carbon, 31.8mm clamp
Headset
FSA IS2 1-1/4 x 1-1/2
Seat
Saddle
Selle Italia Flite Boost SuperFlow Carbon
Seatpost
Cervélo SP24 Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 51cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.43 mm | 1.45 mm | 1.47 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 581 mm | 597 mm | 612 mm | 620 mm |
| Rake | 51 mm | 51 mm | 51 mm | 48 mm |
| Trail | 58.7 mm | 58.7 mm | 58.7 mm | 58.7 mm |
| Stack | 511 mm | 531 mm | 551 mm | 571 mm |
| Reach | 362 mm | 371 mm | 380 mm | 389 mm |
| Top Tube Length | 508 mm | 527 mm | 547 mm | 565 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 510 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 72 ° |
| Head Tube Length | 114 mm | 137 mm | 163 mm | 192 mm |
| Chainstay Length | 416 mm | 416 mm | 416 mm | 416 mm |
| Wheelbase | 989 mm | 1005 mm | 1020 mm | 1028 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 749 mm | 769 mm | 788 mm | 808 mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
R5-CX Red eTap AXS is a Cervelo R5 Cx model. 6 bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Cervélo R5-CX Force eTap AXS 2022 is the cheapest bike model and costs 9000$. Cervélo R5-CX Red eTap AXS 2022 is the most expensive one and costs 13000$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Cyclocross bikes average price
According to our math, the average price for a trustworthy Cyclocross bike is 2012$. However, this doesn’t mean that if you spend less money on a Cyclocross bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Cervélo R5-CX Red eTap AXS price was 13000$. In conclusion, this bike price is 546.12% more expensive than the price of the average Cyclocross bike.
R5-CX Red eTap AXS components
Fork material
R5-CX Red eTap AXS has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When leaving the production line, the R5-CX Red eTap AXS model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Cervélo R5-CX Red eTap AXS has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
