Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset RED AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Cervélo All-Carbon, Tapered R5CX Fork
Drivetrain
Rear Derailleur
SRAM Red AXS, 12 speed
Shift Levers
SRAM Red AXS, 12 speed
Cassette
SRAM Red, 10-33, 12 Speed
Crank
SRAM Red 1 AXS, 40T, DUB, with power meter
Bottom Bracket
SRAM DUB Ceramic, T47 BBright
Chain
SRAM Red, 12 speed
Wheels
Rims
Rear: Reserve 44, 25mm IW, Zipp ZR1 SS,12x142mm, XDR freehub, 24H, centerlock, tubeless compatible Front: Reserve 40, 25.5mm IW, Zipp ZR1 SS, 24H, centerlock, tubeless compatible
Tires
Panaracer CGCX TLC 700x33c
Brakes
Brakes
SRAM Red
Cockpit
Stem
Cervélo ST31 Carbon
Handlebar
Cervélo HB13 Carbon, 31.8mm clamp
Headset
FSA IS2 1-1/4 x 1-1/2
Seat
Saddle
Selle Italia Flite Boost SuperFlow Carbon
Seatpost
Cervélo SP24 Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 51cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.43 mm | 1.45 mm | 1.47 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 581 mm | 597 mm | 612 mm | 620 mm |
| Rake | 51 mm | 51 mm | 51 mm | 48 mm |
| Trail | 58.7 mm | 58.7 mm | 58.7 mm | 58.7 mm |
| Stack | 511 mm | 531 mm | 551 mm | 571 mm |
| Reach | 362 mm | 371 mm | 380 mm | 389 mm |
| Top Tube Length | 508 mm | 527 mm | 547 mm | 565 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 510 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 72 ° |
| Head Tube Length | 97 mm | 118 mm | 139 mm | 157 mm |
| Chainstay Length | 416 mm | 416 mm | 416 mm | 416 mm |
| Wheelbase | 989 mm | 1005 mm | 1020 mm | 1028 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 762 mm | 776 mm | 788 mm | 808 mm |
| Wheels | 700 | 700 | 700 | 700 |
About this model
R5-CX Red eTap AXS completes the Cervelo R5 Cx model. Cervélo launched 6 bikes of this model so far. Take a sneak peek at all Cervelo R5 Cx bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Cervélo R5-CX Force eTap AXS 2023 has a starting price of 8000$. Cervélo R5-CX Red eTap AXS 2023 on the other hand is the most expensive at 11500$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Cyclocross bikes average price
According to our calculations, the average cost of a Cyclocross bike that is reliable is 2012$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2023 for 11500$. Doing a quick comparison, we notice that R5-CX Red eTap AXS price is 471.57% higher than the average cost of a Cyclocross bike.
Overview of components
Fork material
R5-CX Red eTap AXS has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When it comes to wheels, the R5-CX Red eTap AXS bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Cervélo R5-CX Red eTap AXS has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
