Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Cervélo All-Carbon, Tapered R5 Fork
Drivetrain
Rear Derailleur
Shimano Dura-Ace Di2 9250, 12 spd
Front Derailleur
Shimano Dura-Ace Di2 9250, 12 spd
Shift Levers
Shimano Dura-Ace Di2 9270, 12 spd
Cassette
Shimano Dura-Ace CS-R9200, 12 spd, 11-30
Crank
Shimano Dura-Ace 9200 52/36
Bottom Bracket
Ceramic Speed 24
Chain
Shimano CN-M9100, 12 spd
Wheels
Rims
New Reserve 34/37mm DT240, 24h (F), 24h (R), 22.6mm IW (F), 21.6mm IW (R), Center-Lock, Tubeless Ready
Tires
Vittoria Corsa TLR G2.0 25c
Brakes
Brakes
rim
Cockpit
Stem
Cervélo ST31 Carbon
Handlebar
Cervélo HB13 Carbon
Headset
FSA IS2 1-1/4 x 1-1/2
Seat
Saddle
Prologo Scratch M5 NACK OR Selle Italia FLITE BOOST SuperFlow Carbon
Seatpost
Cervelo SP24 Seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.41 mm | 1.45 mm | 1.48 mm | 1.51 mm | 1.53 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 264 mm | 264 mm | 266 mm | 266 mm |
| Front Center | 574 mm | 576 mm | 578 mm | 594 mm | 611 mm | 628 mm |
| Rake | 57.5 mm | 51.5 mm | 45.5 mm | 45.5 mm | 45.5 mm | 45.5 mm |
| Trail | 57.3 mm | 57.3 mm | 57.3 mm | 57.3 mm | 57.3 mm | 57.3 mm |
| Stack | 492 mm | 517 mm | 542 mm | 567 mm | 592 mm | 617 mm |
| Reach | 358 mm | 366 mm | 375 mm | 384 mm | 393 mm | 402 mm |
| Top Tube Length | 510 mm | 526 mm | 543 mm | 559 mm | 576 mm | 593 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 510 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 93 mm | 114 mm | 137 mm | 163 mm | 192 mm | 218 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 967 mm | 969 mm | 972 mm | 989 mm | 1006 mm | 1023 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 72 mm | 72 mm | 69 mm | 69 mm |
| Standover Height | 690 mm | 719 mm | 750 mm | 773 mm | 795 mm | 819 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
R5 Dura Ace Di2 belongs to the Cervelo R5 model. Cervélo launched 33 bikes of this model so far. Take a sneak peek at all Cervelo R5 bikes models from 2022, by clicking here.
Model range prices
Cervélo R5 Force eTap AXS 2022 is the cheapest bike model and costs 8400$. Cervélo R5 Dura Ace Di2 2022 is the most expensive one and costs 12000$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Race bikes
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 12000$. If we compare this with the average Race bike cost we notice that the price is 258.21% more expensive.
R5 Dura Ace Di2 components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The R5 Dura Ace Di2 2022 bike is equipped with 700c carbon wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The R5 Dura Ace Di2 comes with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
