Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Cervélo All-Carbon, Tapered R5 Fork
Drivetrain
Rear Derailleur
Shimano Dura-Ace Di2 9150, 11 speed
Front Derailleur
Shimano Dura-Ace Di2 9150, 11 speed
Shift Levers
Shimano Dura-Ace Di2 9150, 11 speed
Cassette
Shimano Dura-Ace CS-R9100, 11-28
Crank
Shimano Dura-Ace 9100 52/36
Bottom Bracket
BBB Bottomfit BBO-72, PF30 Threaded
Chain
Shimano CN-HG901, 11 speed
Wheels
Rims
ENVE SES 3.4
Tires
Continental Grand Prix 700 x 25c
Brakes
Brakes
Shimano Dura-Ace 9100
Cockpit
Stem
Cervélo Carbon Stem
Handlebar
Cervélo, AB06
Headset
FSA IS2 1-1/8 x 1-1/2
Seat
Saddle
fi’zi:k Antares R5
Seatpost
Cervélo Carbon SP18
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.378 mm | 1.412 mm | 1.442 mm | 1.47 mm | 1.494 mm | 1.52 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 264 mm | 264 mm | 266 mm | 266 mm |
| Front Center | 573 mm | 576 mm | 577 mm | 594 mm | 611 mm | 627 mm |
| Rake | 57 mm | 51 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 57 mm | 57 mm | 57 mm | 57 mm | 57 mm | 57 mm |
| Stack | 499 mm | 524 mm | 548 mm | 572 mm | 596 mm | 620 mm |
| Reach | 362 mm | 371 mm | 380 mm | 389 mm | 399 mm | 408 mm |
| Top Tube Length | 516 mm | 532 mm | 548 mm | 564 mm | 581 mm | 598 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 83 mm | 103 mm | 125 mm | 151 mm | 178 mm | 203 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 972 mm | 974 mm | 976 mm | 993 mm | 1011 mm | 1027 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 72 mm | 72 mm | 69 mm | 69 mm |
| Standover Height | 693 mm | 723 mm | 753 mm | 784 mm | 815 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
R5 Dura Ace DI2 9150 is part of the Cervelo R5 model. 33 bikes variations carry this model name so far. You can easily view all of the Cervelo R5 bikes models from 2018, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The R5 Dura Ace DI2 9150 2018 bike is equipped with 700c carbon wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
