Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED eTAP -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Cerv?©lo All-Carbon, Tapered R5 Fork
Drivetrain
Rear Derailleur
SRAM RED eTap AXS 12 spd
Front Derailleur
SRAM RED eTap AXS 12 spd
Shift Levers
SRAM RED eTap AXS 12 spd
Cassette
SRAM RED XG-1290 10-28
Crank
SRAM RED DUB 48/35
Bottom Bracket
SRAM DUB BBright
Chain
SRAM RED 12 spd
Wheels
Rims
DT Swiss PRC 1450 Spline 35
Tires
Vittoria Corsa Fold 25c
Brakes
Brakes
SRAM RED
Cockpit
Stem
Cerv?©lo Carbon Stem
Handlebar
Cerv?©lo, AB06
Headset
FSA IS2 1-1/8 x 1-1/2
Seat
Saddle
Prologo Zero II STN
Seatpost
Cerv?©lo Carbon SP18
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.42 mm | 1.45 mm | 1.48 mm | 1.5 mm | 1.53 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 264 mm | 264 mm | 267 mm | 266 mm |
| Front Center | 573 mm | 573 mm | 577 mm | 594 mm | 611 mm | 627 mm |
| Rake | 51 mm | 51 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 57 mm | 57 mm | 57 mm | 57 mm | 57 mm | 57 mm |
| Stack | 494 mm | 519 mm | 543 mm | 567 mm | 591 mm | 615 mm |
| Reach | 357 mm | 366 mm | 375 mm | 384 mm | 394 mm | 403 mm |
| Top Tube Length | 511 mm | 511 mm | 543 mm | 559 mm | 576 mm | 593 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 510 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 83 mm | 83 mm | 125 mm | 151 mm | 178 mm | 203 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 967 mm | 969 mm | 971 mm | 988 mm | 1006 mm | 1022 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 72 mm | 72 mm | 68 mm | 69 mm |
| Standover Height | 707 mm | 718 mm | 748 mm | 779 mm | 810 mm | 841 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
R5 Red eTAP AXS Rim belongs to the Cervelo R5 model. There are 33 bikes that carry this model name. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Cervélo R5 Ultegra Rim 2019 is the most affordable bike of this model and has a price of 5000$. On the other hand, Cervélo R5 Dura Ace Di2 Disc 2019, is the most expensive and costs 10500$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Race bikes
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Cervélo released this model in 2019, its price was 9500$. In conclusion, this bike price is 183.58% more expensive than the price of the average Race bike.
R5 Red eTAP AXS Rim components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Cervélo R5 Red eTAP AXS Rim 2019, has a 700c carbon model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
